CAMMICW
– Water-Resistant Line Level Microphone
Thank you for your purchase of Speco Technologies’ CAMMICW Water-Resistant Line Level Microphone.
This microphone can be used in environments where there is the chance of water splash or light spray, or
in indoor applications. Outdoors, this microphone is best installed in a sheltered environment to prevent
direct exposure to the elements.
Features:
Constructed for outdoor use.
Pickup in rooms up to 120 sq. ft.
Built-in high-speed voice processing
Built-in self-gain control AGC processing circuit, which helps prevent signal distortion
Built-in lightning protection, reverse polarity power protection and power protection module
Integrated pre-amplification processing circuit
Recommended transmission distance of 25’ – optional accessory UTPAUDIO is available for
transmission up to one mile over UTP cable
Requires power supply (not included). PSW5 is recommended.
Operation:
Red connector is for your power supply (not included).
White connector is the line level output for connection to an RCA cable.
Microphone should be installed as close to intended audio source as possible
Please ensure proper power and voltage is being used before installation to ensure no damage is
done to microphone.
Specifications:
Range 10~120 Square
Sensitivity -43DB 1000 HZ
S/N Max 65dB
Operating voltage
9~12VDC
25MA (Power Supply
not included)
Size 3” diameter x 1” H (75*25
mm
)
Connections Red (power is),
black (GND, signal to),
white
(
audio
signal)
Speco Technologies is constantly developing and improving products.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
Speco Technologies 200 New Highway Amityville NY 11701 ● ● ● ● ● www.specotech.com
Rev. 04/02/20
