200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
!"#$%&"'%&(
Side View!
)$*+,-$&(
Front View!
Unit : inch!
HD-TVI 4MP IR Outdoor Mini Turret Camera
Wall/Ceiling Mount, UTC, Multi-Format (TVI, AHD, CVI, CVBS)
HT471TG – Grey, 2.9mm HT471TW – White, 2.9mm
1 Wrench
1 Power lead
3 Mounting screws
Accessories!
&.$/")"/*+"'%&(
Image Sensor.................. 1/3” Progressive Scan CMOS, 4MP
Minimum Illumination....... 0.00 lux (IR LED on)
IR LED wavelength…....... 850nm
Effective Pixels................ 2184 (H) x 2202 (V)
Total Pixels...................... 3096 (H) x 2281 (V)
Scanning System............ Progressive
S/N Ratio......................... More than 50dB
Output Resolution............ 2560 x 1440 @ 30fps & 15fps (default)
1920x1080 @ 30fps
Video Output.................... 1.0Vp-p / 75 Ohms
(TVI-default / AHD / CVI / CVBS)
Electronic Shutter............ Auto / Manual (1/30 – 1/30,000 sec.)
Day / Night....................... Auto / Color / BW / External
Power............................. 12VDC (power supply not included)
Power Consumption........ 12VDC, 300mA max.
Operating Temperature.... -4° F – 122° F
Unit Dimensions.............. 2.15” (H) x 2.36” (Dia.)
Unit Weight...................... 10 oz.
Certifications.................... FCC, RoHS
Signal Distance............... Up to 1600 feet
(depending on coax quality)*
• Quad / Full HD resolution over coax
• Supports 4MP @ 30fps & 15fps (default), 2MP@30fps
• Multi-format HD (TVI - default, CVI, AHD, CVBS)
• True day/night operation – mechanical IR cut filter
• Compact size – only 2.36” in diameter
• 12 IR LEDs (IR range 35’)
• Weather (IP66 compliant) / Vandal resistant operation
• 3-axis for wall and ceiling mounting
• Full OSD operation & Video format change through UT
C or Joystick built-in Cable
• Signal distance up to 1600 feet*
• 12VDC required
• 5 year warranty
*$(
• !"#$! • !!%&'%()!
• !*+((,(! • !-.$-(!
!*0(1(%"23+(
"#*2$($%3*%/$(
4*%2,*2$(
$5"+(
• !"(+/0')%11!
• !%&2,13(%!
*67(
• !*$"!
• !4'$!
• !43',!
• !5,)'(41'! • !104(2)%11!
&* 8$1$5"+(
• !5,6,(!
-$&$+(
• !5,6,(!/4+)! • !-)(!
0-!.!40-!#!'7+!#!57+!#!57"1!
8"!$'(',+(
7+-%,!1'4)-4(-!8!9*2!:;<=>?!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!9*2!@>!!A57+!BCDE!DCEFGHI!JKLE!IJMF!CNOCG!
!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!!@;P;!:;<=>?!
'&!(#$%,(+-$$((
9:;<=>?;(,+/(=<(@=ABCDE(F>GH:1GI(DJFHKL(
☆
Push 2sec. to change Video format
