ITEM №: HT7PHT
Caution for Installation
1. In order to prevent electronic shock, don’t loosen any screws or covers.
2. Do not directly touch the front glass. If necessary, use a soft cloth
moistened with alcohol to wipe off the dust.
3. Avoid places where there are frequent vibrations or shocks.
4. Don’t operate the camera beyond its temperature, power source
ratings.
5. When any abnormalities happen, make sure to unplug the camera and
contact your local dealer.
Packing
1. Camera X1
2. User Manual X1
3. Screw X2
4. Plastic-Conical-Anchor X2
5. Hexagonal Wrench X1
Specification
ITEM
HT7PHT
IP Rating
IP55
Type
Colour
Signal System
NTSC/PAL
Pick Up Device
1/2.9" 2.2 Mega Pixels CMOS
Picture Elements
1920(H)X1080(V)
Min Illumination
0.001 LUX
S/N Ratio
≥52dB
Lens
3.7mm Pin Hole Lens
3D/2D
ON
SENS-UP
ON
IR SMART
ON
White Balance
ATW
Back Light Compensation
OFF
DWDR
ON/OFF
OSD
With UTC Signal(DVR Control OSD)
Video Out-put
HD-TVI/HD-AHD/HD-CVI/CVBS
Power Supply
DC12V ±10%
Current Consumption
70mA(MAX)
Dimension
45×38.5×24mm (1.77"×1.5"×0.98")
Weight
70g (2.47oz)
Storage Temperature
-30～+60℃ (-22～+140℉)
Operating Temperature
-30～+45℃ (-22～+113℉)
Remark: Non-regulative adaptor may cause camera damaged
Analog High Definition 4 in 1 Mini Camera
