OSD MENU TREE
960H 700TVL Color Indoor Dome Camera with 24LEDs
HLED33D1B – 2.8~12mm auto iris lens, black housing
HLED33D1W – 2.8~12mm auto iris lens, white housing
HLED33D7B – 3.6mm lens, black housing
HLED33D7W – 3.6mm lens, white housing
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
DIMENSIONS
Side View
*Accessories *
3 mounting screws
1 Power Cable
1 Video Cable
SPECIFICATIONS
Bottom View
OSD MENU TREE
EXPOSURE
• ALC / ELC
• CDS • EXTERN
• BACKLIGHT • PRIVACY• CONTRAST • POSI/NEGA • H-MIRROR
• CAM TITLE • CAM ID • ID DISP.
• LANGUAGE • SPECIAL
DAY&NIGHT
MONITOR
SYSTEM
EXIT
(SAVE/RESTORE/INITIAL/MANUAL)
• SHUTTER
• FLK
• AGC
• LENS
• BRIGHTNESS
• GAMMA • CHROMA • SHARPNESS • SHADING • PED.LV.
• ATW • MANUAL
WHITE BAL.
DNR
• LOW • MIDDLE • HIGH • OFF
MOTION
• ON • OFF
• SYNC
• OFF • D-WDR • DEFOG
ITEM 960H 700TVL IR Indoor Dome Camera
Lens
HLED33D1B(W) – 2.8~12mm auto iris lens
HLED33D7B(W) - 3.6mm fixed lens
Image Sensor 1/3” COLOR 960H CCD
Resolution 700TV lines
Total Pixels 1020(H) x 508(V) (NTSC)
Effective Pixels 976(H) x 494(V) (NTSC)
Scanning System 2 : 1 Interlace
Synchronization Internal
Min. Illumination 0.00Lux (LED-On)
Number of IR LEDs 24LEDs
IR Range 65’ (depending on scene reflection)
S/N (Y signal) 50dB
AGC Level Adjustable
Shutter 1/60~1/120,000sec (NTSC)
DAY / NIGHT AUTO / NIGHT / DAY
Image BLC / D-WDR / DEFOG
White Balance ATW / PUSH / MANUAL
DNR LOW / MIDDLE / HIGH
Motion Detection ON | OFF (4 Programmable Zone)
Privacy Masking ON | OFF (8 Programmable Zone)
Power Consumption 350mA
Power Supply 12VDC / 24VAC Dual Voltage
Operational Temp. 14
°
F - 122
°
F
Storing Temp. -4
°
F - 140
°
F
Dimensions 3.4” (H) x 4.4” (Dia.)
Weight 8oz.
SPECIFICATIONS
• SENS UP
• AUTO • NIGHT• DAY
• PUSH
• BLC • HLC
• BAUDRATE
• SMART IR
