! ITEM №: VLDT3WM/ VLDT3GM
! Caution for Installation
1. In order to prevent electronic shock, don’t loosen any screws or covers.
2. Do not directly touch the front glass. If necessary, use a soft cloth
moistened with alcohol to wipe off the dust.
3. Avoid places where there are frequent vibrations or shocks.
4. Don’t operate the camera beyond its temperature, power source ratings.
5. When any abnormalities happen, make sure to unplug the camera and
contact your local dealer.
! Packing
1. Camera X1
2. Junction box X1
3. User Manual X1
4. 4*34mm Screw X4
5. 4*20mm Screw X4
6. Plastic-Conical-Anchor X4
7. Junction box cotton pad X1
8. Hexagonal Wrench X1
9. Mounting drawing paper X1
! Specification
ITEM
VLDT3WM/VLDT3GM
IP Rating
IP66
Type
Removable IR Cut Filter
Signal System
NTSC/PAL
Pick Up Device
1/2.9" 2.2 Mega Pixels CMOS
Picture Elements
1920(H)X1080(V)
Min Illumination
0Lux（18 Pieces IR LED ON）
S/N Ratio
≥52dB
Lens
2.8-12mm Motorized Vari-focal Fixed Iris Lens
3D/2D
ON
SENS-UP
ON
IR SMART
ON
White Balance
ATW
Back Light Compensation
OFF
DWDR
ON/OFF
OSD
With UTC Signal(DVR Control OSD)
Video Out-put
HD-TVI/HD-AHD/HD-CVI/CVBS
Power Supply
DC12V ±10%
Current Consumption
500mA(MAX)
IR Effect Distance
49.2~65.6ft(indoor)
Dimension
Φ4.72”×3.93” inch
Weight
790g（27.86oz）
Storage Temperature
-22～+140
Operating Temperature
-22～+104
Junction box
Dimension
Φ4.72””×1.59” inch
Weight
255g (9.0oz)
Remark: Non-regulative adaptor may cause camera damaged.
Multi-Format HD Analog IR Camera
