APPLICATIONS
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2015 METRA ELECTRONICS CORPORATION
REV. 4/24/2015 INST99-7805CH
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
Table of Contents
INSTALLATION INSTRUCTIONS FOR PART 99-7805CH
• ISO DIN radio provision with pocket
• Painted charcoal gray
• A) Radio trim panel • B) Radio brackets • C) Pocket • D) (4) #8 x 3/8” Truss-head Phillips screws
• E) (2) #8 x 1/2” Truss-head Phillips screws • F) (4) #8 x 3/8” Pan-head Phillips screws
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • 70-1729 - For non-amplified models
• 70-1730 - For amplified models
Antenna Adapter: • 40-HD10
• Panel removal tool • Phillips screwdriver
• Socket wrench
TOOLS REQUIRED
Acura TSX (without nav) 2009-2014
99-7805CH
A
B C D
F
E
Dash Disassembly
– Acura TSX (without nav) 2009-2014 ..................2-5
Kit Assembly
– ISO DIN radio provision with pocket ...................... 6
