APPLICATIONS
METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2004-2013 METRA ELECTRONICS CORPORATION
REV. 2/20/2014 INST95-7510
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
INSTALLATION INSTRUCTIONS FOR PART 95-7510
• Double DIN radio provision
• Stacked ISO radio provision
• Two finishes available: 95-7510 = Black,
95-7510HG = Gloss Black
• A) Radio/Climate control housing • B) Radio brackets • C) Rear support • D) Interface
• E) Wiring harnesses • F) (2) Climate control extension harnesses • G) (4) Plastic panel clips
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • Harness included
Antenna Adapter: • Not required
• Panel removal tool • Phillips screwdriver
• Socket set • Small flat blade screwdriver
• Cutting tool
TOOLS REQUIRED
Mazda RX-8 2004-2008
95-7510, 95-7510HG
A
B C D E
Dash Disassembly
– Mazda RX-8 2004-2008 ....................................2-3
Kit Assembly
– Double DIN and stacked ISO radio provisions ....... 4
– Interface installation ..........................................5-6
F G
Table of Contents
