METRA. The World’s best kits.
™
metraonline.com1-800-221-0932
© COPYRIGHT 2015 METRA ELECTRONICS CORPORATION
REV. 3/17/2015 INST99-7804B
CAUTION: Metra recommends disconnecting the
negative battery terminal before beginning any
installation. All accessories, switches, and especially
air bag indicator lights must be plugged in before
reconnecting the battery or cycling the ignition.
NOTE: Refer to the instructions included with the
aftermarket radio.
Installation Instructions for 99-7804B
• ISO DIN radio provision with pocket
• DDIN radio provision
• Painted two tone to match factory
• Retains factory color screen
• A) Radio housing trim panel • B) Brackets • C) Top bracket • D) Pocket • E) (6) White panel clips
• F) (8) #6 x 3/8” Phillips screws • G) (8) #8 x 3/8” Phillips screws • H) Display retention interface and harness (not shown)
KIT FEATURES
KIT COMPONENTS
WIRING & ANTENNA CONNECTIONS (sold separately)
Wiring Harness: • Included
Antenna Adapter: • 40-HD11
• Panel removal tool • Phillips screwdriver
TOOLS REQUIRED
Honda Accord 2013-up
99-7804B
A
F
B
G
C D E
Dash Disassembly
– Honda Accord 2013-up .......................................2-3
Kit Assembly
– Kit preparation ..................................................... 4
– ISO DIN radio provision with pocket ...................... 5
– DDIN radio provision ............................................ 6
Wiring Instructions ............................................. 7-8
Touch Screen Instructions................................ 9-10
Table of Contents
