INSTALLATION INSTRUCTIONS
99-7527S
Metra. The World’s Best Kits.
®
MetraOnline.com © COPYRIGHT 2019 METRA ELECTRONICS CORPORATION REV. 7/24/19 INST99-7527S
Attention! Let the vehicle sit with the key
out of the ignition for a few minutes before
removing the factory radio. When testing the
aftermarket equipment, ensure that all factory
equipment is connected before cycling the
key to ignition.
KIT FEATURES
• ISO DIN radio provision with pocket
• DIN radio provision with pocket
• ISO DDIN radio provision
• Painted silver
• Storage pocket included to replace the factory NAV screen
KIT COMPONENTS
• A) Radio Housing • B) ISO Brackets • C) ISO Trim Plate • D) Double DIN Brackets • E) Double DIN Trim Plate • F) Snap In Pocket
• G) NAV Screen Replacement Pocket
TOOLS REQUIRED
• Panel removal tool • Phillips screwdriver
• Socket wrench
TABLE OF CONTENTS
Dash Disassembly ...............................................2-3
Kit Preparation .......................................................4
Kit Assembly
–DIN radio provision with pocket ........................5
–ISO DIN radio provision with pocket ..................6
–ISO DDIN radio provision .....................................7
WIRING & ANTENNA CONNECTIONS
(sold separately)
Wiring Harness: 70-7903
Antenna Adapter: Not required
A CB
Mazda 5 (with factory NAV) 2006-2007
D E
F G
Visit MetraOnline.com for more detailed information about the product and up-to-date vehicle
specific applications
