Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\4010280_01018.doc
Erstelldatum/create date: 18.02.2009 10:00:00Aktualisiert/up dated: 04.03.2009
1
2
3
3
4
5
6
7
Technical Data
Mains connection: 230 V ~ 50 Hz
Motor rating: 1.1 kW (1.5 HP) S3 25%
Intake capacity: 180 l / min
Output power: at 0 bar: 139 l/min
at 4 bar: 77 l/min
at 7 bar: 63 l/min
Tank capacity (liters): 6 l
Speed (Pump): 3,550 rpm
Operating pressure: max. 8 bar
No. of cylinders: 1
Net weight: 9.1 kg
Gross weight: 10.2 kg
Packing dimensions: 510 x 230 x 520 mm
Bar code: 4006825 557381
Sales unit: 1 pc
BT-AC 160/6 OF
Air Compressor
Art.-No. 40.102.80
Features
Transport handle (1)
Drain valve (2)
Base foot with vacuum cup function (3)
Pressure controller (4)
Pressure gauge (6) and quick coupling (5) for
regulated working pressure
Well amenable on/o switch (7)
Intake lter
Non-return valve
Safety valve
Oil-free and thus low-maintenance
10 years warranty against rusting through
of the tank
The use of special components at the air compressor makes the renouncement of oil lubrication possible. Thus the
compressor is particularly low maintenance, because no oil level must be controlled and no oil must be relled. By the small
compressed-air vessel the air compressor is ideally useable in mobile application.
