Abbildungen können nicht im Serien-Lieferumfang enthaltenes Zubehör darstellen / Illustrations can contain accessories, which are not included in standard extent of delivery.
Abbildungen ähnlich, produktionsbedingte Abweichung vorbehalten / Illustration similar (in design), production-wise modications reserved.
File: S:\shared-pool\Product-Documentation\T-Produktbeschreibung\30_n0t\Originale_Englisch_PA04\4010260_01018.doc
Erstelldatum/create date: 30.10.2008 16:17:00Aktualisiert/up dated: 14.11.2008
1 2
3
4
5
6
7
8 9 10 11
Technical Data
Mains connection: 220 - 240 V ~ 50 Hz
Motor rating: 1.5 kW (2 HP) S3 25%
Intake capacity: 210 l / min
Output power: at 0 bar: 118 l/min
at 4 bar: 93 l/min
at 7 bar: 74 l/min
Tank capacity (liters): 24 l
Speed: 2,850 rpm
Operating pressure: max. 8 bar
No. of cylinders: 1
Net weight: 25.0 kg
Gross weight: 26.0 kg
Packing dimensions: 600 x 255 x 550 mm
Bar code: 4006825 554731
Sales unit: 1 pc
BT-AC 190/24
Air Compressor
Art.-No. 40.102.60
Features
Transport handle (1)
Pressure switch (2)
Intake lter (3)
Oil level control with dipstick (4)
Big wheels for easy transport (5)
Drain valve (6)
Pressure reducer (7)
Quick-release coupling (8) and pressure gauge (9)
for regulated working pressure
Pressure gauge (10) for reading the tank pressure
Safety valve (11)
Non-return valve
Pump lubricated with oil
10 years warranty against rusting through of
the tank
