Side 1/6
EN
EN • 3
CHARGING
1. Connect the charger to the battery.
2. Connect the charger to the wall socket. The power lamp will indicate that the mains
cable is connected to the wall socket. The error lamp will indicate if the battery clamps
are incorrectly connected. The reverse polarity protection will ensure that the battery
or charger will not be damaged.
3.Press the MODE-button to select charging program.
4. Follow the indication lamps through the charging process.
The battery is ready to start the engine when is lit.
The battery is fully charged when is lit.
5. Stop charging at any time by disconnecting the mains cable from the wall socket.
MANUAL
ABSORPTION, READY TO USE
ANALYSE
NORMAL
BAT TERY
PROGRAM
ERROR LAMP
RECOND
PROGRAM
SUPPLY
PROGRAM
POWER
LAMP
MODE-
BUTTON
DESULPHATION
SOFT START
BULK FLOAT, FULLY CHARGED
PULSE, MAINTENANCE CHARGING
TEMPERATURE
SENSOR
INDICATOR
24V/14A
MXT 14
MODE
SUPPLYNORMAL RECOND
RECOND
SUPPLY
24V/14A
MXT 14
MODE
SUPPLYNORMAL RECOND
RECOND
SUPPLY
SUPPLY PLUG*
L: 2000 mm
TEMPERATURE
SENSOR
CONGRATULATIONS
to the purchase of your new professional switch mode battery
charger. This charger is included in a series of professional
chargers from CTEK SWEDEN AB and represents the latest
technology in battery charging.
MAINS CABLE
*Supply plugs may differ to suit your wall socket.
20015551E MXT 14, Manual EU, Print file 001.indd 3 2013-07-23 11:31:02
Problemløsning Ctek MXT 14
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 130 mm |
| Dybde: | 235 mm |
| Højde: | 65 mm |
| Vægt: | 1900 g |
| Produktfarve: | Blue, Silver |
| Batterispænding: | 2 V |
| Driftstemperatur (T-T): | -20 - 50 °C |
| Indgangsspænding: | 220-240 V |
| Indgangsfrekvens: | 50/60 Hz |
| Kabelfarve: | Sort |
| Aktuel opladning: | 14 |
