Smaller
Allen Key
Instructions:
1. Installing the Clamp
1. Place rubber grip flat insert into the clamp groove. Rotate
tightening handle counter-clockwise to widen around
surface ledge. Rotate clockwise to tighten until secure.
On a Flat Surface:
2. Remove rubber grip flat insert from clamp groove. Rotate
tightening handle counter-clockwise to widen around surface
ledge. Rotate clockwise to tighten until secure.
On a Tube:
2. Connecting the Tablet Gooseneck Holder
1. Screw gooseneck onto the male metal
connection bolt on top of the clamp.
Note
: if meter screws are already in,
unscrew before attaching gooseneck.
2. Use the smaller Allen key to screw up
two meter screwes insde the gooseneck,
tightening the connection.
Heavy-Duty Gooseneck Clamp Stand
for 7-13 Inch Tablets
PAD-HGT
SUPPORT@CTADIGITAL.COM
3. To use clamp aligned vertically,
screw gooseneck onto the male metal
connection bolt on the side of the clamp.
Smaller
Allen Key
4. Use the smaller Allen key to screw the
two meter screws insde the gooseneck,
tightening the connection.
1. Press the button on the side of the
holder center to slide out holder arm.
Insert your tablet against the spring
end, then slide the other arm back in,
closing firmly.
2. Use the bigger Allen key to tighten
and loosen the gooseneck to holder
connection, adjusting ease of rotation.
3. Installing Your Device and Adjusting the Gooseneck and Tablet Holder:
Bigger
Allen Key
Multi
direction
flexing
3. Flex the gooseneck to multi
direction and adjust it freely according
to your needs.
Problemløsning CTA Digital PAD-HGT
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | Passiv holder |
| Vægt: | 1446 g |
| Produktfarve: | Sort, sølv |
| Pakkedybde: | 100 mm |
| Pakkebredde: | 365 mm |
| Pakkehøjde: | 259 mm |
| Indbyggede højttaler(e): | Ingen |
| Strømkilde type: | Ikke understøttet |
| Normal brug: | Indendørs |
| Rotationsvinkel: | 360 ° |
| Armlængde: | 398 mm |
| Mobil enhedstype: | Tablet/UMPC |
| Maksimal skærmstørrelse kompatibilitet: | 13 " |
| Orientering: | Horisontal/vertikal |
| Beslagtype til enhed: | Klemmebeslag |
| Minimal skærmstørrelse kompatibilitet: | 7 " |
