Crux Interfacing Solutions • 6860 Canby Ave., Suite 104, Reseda, CA 91335
phone: (818) 609-9299 • fax: (818) 996-8188 • www.cruxinterfacing.com
rev.021919
VIMVL-98A
VIM Activation for Select
VOLVO Vehicles with RTI 2011 Navigation System
1 of 2
- Retains funconality of Factory-installed Navigaon System for passenger access at anyme
- Allows onscreen access to Factory Bluetooth Keypad*
- Allows for Navigaon Desnaon Address Entry at anyme*
- Designed for OEM equipment only
*Subject to capability of Factory-installed Navigaon System.
PRODUCT FEATURES:
R
INTERFACING SOLUTIONS
Sightline
VIDEO IN-MOTION ACTIVATION
PARTS INCLUDED:
VIMVL-98A MODULE VIMVL-98A HARNESS
INSTALLATION DIAGRAM:
Installaon of the VIMVL-98A is done at the factory navigaon screen 16 pin connector.
TO FACTORY
SCREEN
FROM FACTORY
RADIO HARNESS
DP
ON
DIP
SWITCH
LED*
*LED RED = Power ON Status
LED BLUE = Data Bus ON Status
8-Pin Molex
GREEN WIRE
NON PERMANENT
ACTIVATION OF VIDEO BYPASS
(See VIM Activation on page 2)
+12V ACC
(Toggle switch NOT included)
