Side 1/4
Series 8, wall-mounted cooker hood,
90 cm, clear glass white printed
DWK98PR20I
DWZ0AK0R0 Long Life recirculation kit (chimless)
DWZ0AK0S0 Long Life recirculation kit
DWZ0AX5K0 Chimney extension 1000 mm
DWZ0AX5L0 Chimney extension 1500 mm
DWZ1AK1B6 Clean Air Plus odor filter (replacement)
DWZ1AK1I6 Clean Air Plus recirculation kit
DWZ1AK1V6 Clean Air Plus recirc. kit (chimless)
DWZ1AX5C6 Clean Air Plus recirc. kit external
DZZ0XX0P0 Long Life odor filter (replacement)
DZZ1XX1B6 Clean Air Plus odor filter (replacement)
The wall-mounted chimney hood: mount it
on the wall, giving you complete freedom
in your kitchen planning.
• : PerfectAir sensor enjoy quieter, odour-free cooking.
• : Extra quiet maximum extractor performance with minimal noise.
• : Easy-to-clean interior hidden screws and cables along with
rounded edges make cleaning easy.
• : Cooktop-based Hood Control convenient operation of the hood via
your hob.
• : Home Connect control your hood via the app.
Typology: .......................................................................Wall-mounted
Length electrical supply cord: .............................................. 130.0 cm
Height of product, without chimney: ...................................... 323 mm
Net weight: ..............................................................................26.4 kg
Type of control: ...................................................................Electronic
Number + 2 of speed settings: ..................................3-stage intensive
Max. air extraction: ...............................................................468 m³/h
Boost position output recirculating: .....................................460 m³/h
Max. air recirculation: .......................................................... 378 m³/h
Boost position air extraction: ............................................... 837 m³/h
Number 2of lights: ..............................................................................
Noise level: ...............................................................55 dB(A) re 1pW
Diameter / of air outlet: .................................................. 120 150 mm
Grease filter material: .........................................Washable aluminium
Odour filter: ................................................................................... No
Operating Mode: ...............................................................Convertible
Optional accessories: ......... DWZ0AK0R0, DWZ0AK0S0, DWZ0AX5K0,
DWZ0AX5L0, DWZ1AK1B6, DWZ1AK1I6, DWZ1AK1V6, DWZ1AX5C6,
DZZ0XX0P0, DZZ1XX1B6
Type of lamps used: ..................................................................... LED
Grease filter type: ................................................. Multilayer cassette
Clean filter reminders: ...................................................................Yes
Connection Wrating: .................................................................... 166
Fuse Aprotection: ...........................................................................10
Voltage: V............................................................................... 220-240
Frequency: ........................................................................... 50; 60 Hz
Plug type: ....................................................... India plug (10 Ampere)
Installation typology: .....................................................Wall-mounted
Plug type: ....................................................... India plug (10 Ampere)
Dimensions x xof the product, with chimney (if exists) (in): ...............
Dimensions x x of the packed product: .................. 27.16 29.13 40.94
Net weight: .........................................................................58.000 lbs
Gross weight: ..................................................................... 77.000 lbs
Motor location: ................................... Integrated motor in hood body
No-return airflow flap: ................................................................... Yes
Length electrical supply cord: .............................................. 130.0 cm
Dimensions x xof the product, with chimney (if exists): ....480 894.0
548.0 mm
Dimensions x x of the packed product (HxWxD): ... 690 740 1040 mm
Net weight: ..............................................................................26.4 kg
Gross weight: .......................................................................... 35.1 kg
