Side 1/3
Series 4, wall-mounted cooker hood,
60 cm, Flat black
DWBA68J60I
DWZ3OX6N1 Inner duct cover 320 mm
The wall-mounted chimney hood: mount it
on the wall, giving you complete freedom
in your kitchen planning.
• For fast and effective extraction, the intensive speed setting
removes strong kitchen odours quickly and effectively.
Typology: .......................................................................Wall-mounted
Length electrical supply cord: .............................................. 180.0 cm
Height of product, without chimney: ...................................... 527 mm
Net weight: ..............................................................................21.0 kg
Type of control: ...................................................................Electronic
Number + of speed settings: ....................... 3-stages intensive setting
Max. air extraction: .............................................................. 700 m³/h
Number 2of lights: ..............................................................................
Noise level: ...............................................................67 dB(A) re 1pW
Diameter of air outlet: ............................................................180 mm
Odour filter: ................................................................................... No
Operating Mode: .................................................... Air extraction only
Optional accessories: ..................................................... DWZ3OX6N1
Total 3 Wpower of the lamps: .............................................................
Clean filter reminders: ....................................................................No
Voltage: V......................................................................................230
Frequency: ................................................................................. 50 Hz
Plug type: ......................................................... India plug (6 Ampere)
Installation typology: .....................................................Wall-mounted
Material body: ................................................................... zinc plated
Plug type: ......................................................... India plug (6 Ampere)
Dimensions x xof the product, with chimney (if exists) (in): ...............
Dimensions x x of the packed product: .................. 24.01 22.83 27.75
Net weight: .........................................................................46.000 lbs
Gross weight: ..................................................................... 57.000 lbs
Motor location: ..............................Integrated motor in hood chimney
No-return airflow flap: ................................................................... Yes
Length electrical supply cord: .............................................. 180.0 cm
Dimensions x xof the product, with chimney (if exists): ....527 600.0
506.0 mm
Dimensions x x of the packed product (HxWxD): ..... 610 580 705 mm
Net weight: ..............................................................................21.0 kg
Gross weight: .......................................................................... 26.0 kg
1 /
