AXRSEH -GL29 AXRSEH -GL29 AXRSEH -GL29
INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS INSTALLATION INSTRUCTIONS
REV. 4/20/20 REV. 4/20/20 REV. 4/20/20
© COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION
Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com Integrate • AxxessInterfaces.com
• Retains the A/V-IN jack (if applicable)
• Provides A/V output to the factory installed rear seat overhead
entertainment system *
• Designed for models that have a DVD player built into the factory radio
• Retains the A/V-IN jack (if applicable)
• Provides A/V output to the factory installed rear seat overhead
entertainment system *
• Designed for models that have a DVD player built into the factory radio
• Retains the A/V-IN jack (if applicable)
• Provides A/V output to the factory installed rear seat overhead
entertainment system *
• Designed for models that have a DVD player built into the factory radio
INTERFACE FEATURES INTERFACE FEATURES INTERFACE FEATURES
• Wire cutter • Crimping tool
• Connectors (example: butt-connectors, bell caps, etc.)
• Wire cutter • Crimping tool
• Connectors (example: butt-connectors, bell caps, etc.)
• Wire cutter • Crimping tool
• Connectors (example: butt-connectors, bell caps, etc.)
TOOLS REQUIRED TOOLS REQUIRED TOOLS REQUIRED
GM RSE A/V Harness 2007-Up GM RSE A/V Harness 2007-Up GM RSE A/V Harness 2007-Up
APPLICATIONS APPLICATIONS APPLICATIONS
• AXRSEH-GL29 harness • AXRSEH-GL29 harness • AXRSEH-GL29 harness
• Connect to the AXRSEH-GL29 harness to the wiring harness in the
vehicle located at the radio location.
• Connect to the AXRSEH-GL29 harness to the wiring harness in the
vehicle located at the radio location.
• Connect to the AXRSEH-GL29 harness to the wiring harness in the
vehicle located at the radio location.
INTERFACE COMPONENTS INTERFACE COMPONENTS INTERFACE COMPONENTS
CONNECTIONS TO BE MADE CONNECTIONS TO BE MADE CONNECTIONS TO BE MADE
INSTALLATION INSTALLATION INSTALLATION
BUICK
Enclave 2008-Up
Cadillac
Escalade 2007-2011
Escalade ESV 2007-2011
Escalade EXT 2007-2011
SRX 2007-2009
CHEVROLET
Avalanche ∆ 2007-2013
Equinox 2007-2009
Silverado 2500/3500 ∆ 2014
Silverado (new body) ∆ 2007-2013
Suburban ∆ 2007-2014
Tahoe ∆ 2007-2014
Traverse 2009-Up
GMC
Acadia 2007-2016
Acadia Limited 2017
Sierra 2500/3500 ∆ 2014
Sierra (new body) ∆ 2007-2013
Yukon/Yukon XL ∆ 2007-2014
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
SUZUKI
XL-7 2007-2009
BUICK
Enclave 2008-Up
Cadillac
Escalade 2007-2011
Escalade ESV 2007-2011
Escalade EXT 2007-2011
SRX 2007-2009
CHEVROLET
Avalanche ∆ 2007-2013
Equinox 2007-2009
Silverado 2500/3500 ∆ 2014
Silverado (new body) ∆ 2007-2013
Suburban ∆ 2007-2014
Tahoe ∆ 2007-2014
Traverse 2009-Up
GMC
Acadia 2007-2016
Acadia Limited 2017
Sierra 2500/3500 ∆ 2014
Sierra (new body) ∆ 2007-2013
Yukon/Yukon XL ∆ 2007-2014
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
SUZUKI
XL-7 2007-2009
BUICK
Enclave 2008-Up
Cadillac
Escalade 2007-2011
Escalade ESV 2007-2011
Escalade EXT 2007-2011
SRX 2007-2009
CHEVROLET
Avalanche ∆ 2007-2013
Equinox 2007-2009
Silverado 2500/3500 ∆ 2014
Silverado (new body) ∆ 2007-2013
Suburban ∆ 2007-2014
Tahoe ∆ 2007-2014
Traverse 2009-Up
GMC
Acadia 2007-2016
Acadia Limited 2017
Sierra 2500/3500 ∆ 2014
Sierra (new body) ∆ 2007-2013
Yukon/Yukon XL ∆ 2007-2014
HUMMER
H2 2008-2009
PONTIAC
Torrent 2007-2009
SATURN
Outlook 2007-2010
SUZUKI
XL-7 2007-2009
* Only applicable for models with a second row RSE * Only applicable for models with a second row RSE * Only applicable for models with a second row RSE
∆ For 2012-Up models with NAV use the AXRSEH-G2. ∆ For 2012-Up models with NAV use the AXRSEH-G2. ∆ For 2012-Up models with NAV use the AXRSEH-G2.
•
Connect the Black wire with a ring terminal to the chassis of the aftermarket radio
.
• From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the
aftermarket radio:
• Connect the Yellow RCA jack to the video in.
• Connect the Red and White RCA jacks to the audio in.
• From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the
aftermarket radio:
• Connect the Yellow RCA jack to the video out.
• Connect the Red and White RCA jacks to the audio out.
•
Connect the Black wire with a ring terminal to the chassis of the aftermarket radio
.
• From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the
aftermarket radio:
• Connect the Yellow RCA jack to the video in.
• Connect the Red and White RCA jacks to the audio in.
• From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the
aftermarket radio:
• Connect the Yellow RCA jack to the video out.
• Connect the Red and White RCA jacks to the audio out.
•
Connect the Black wire with a ring terminal to the chassis of the aftermarket radio
.
• From the RCA jacks labeled “FROM REAR A/V INPUT” to the A/V input of the
aftermarket radio:
• Connect the Yellow RCA jack to the video in.
• Connect the Red and White RCA jacks to the audio in.
• From the RCA jacks labeled “TO OVERHEAD SCREEN” to the A/V output of the
aftermarket radio:
• Connect the Yellow RCA jack to the video out.
• Connect the Red and White RCA jacks to the audio out.
