AXDSPX-TY3
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2025 METRA ELECTRONICS CORPORATION REV. 03/17/2025 INSTAXDSPX-TY3
INTERFACE FEATURES
TOOLS & INSTALLATION ACCESSORIES REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip-ties • Multimeter
TABLE OF CONTENTS
Installation & Installation Options ........................2
Connections ........................................................3-4
AX-DSP-XL App: Quick Setup ............................5-6
Specifications ......................................................... 7
APPLICATIONS
Visit AxxessInterfaces.com for current application list
INTERFACE COMPONENTS
• AXDSPX-TY3 interface
• AXDSPX-TY3 interface harness
• AXDSPX-TY3 vehicle T-harness
• Bass knob
DSP Interface with Pre-Wired Harness
Fits Select Toyota Models
2018-Up
www.MetraOnline.com
MetraOnline.com may be used to assist
with dash assembly instructions. Simply
enter your Year, Make, Model vehicle
into the vehicle fit guide and look for the
Dash Kit Installation Instructions.
• Designed for both amplified and non-amplified models
• AXDSP-X interface and vehicle-specific T-harness included
• Selectable 31 Band Graphic EQ or 5 Band Parametric EQ
• 10 individually assignable outputs
• Independent equalization on each of the 10 outputs
• Independent high pass, low pass, and band pass filters
• Each channel can be delayed independently up to 10ms
• Clipping detection and limiting circuits
• U.S. Patent 9,875,078
• Easy behind the radio installation with pre-wired harness
(Features continued on next page)
Download the AX-DSP-XL App
iOS
®
12.1 or higherAndroid™ 9 or higher
ATTENTION: With the key out of the ignition,
disconnect the negative battery terminal before
installing this product. Ensure that all installation
connections, especially the air bag indicator lights, are
plugged in before reconnecting the battery or cycling
the ignition to test this product.
NOTE: Refer also to the instructions included with the
aftermarket accessory before installing this device.
