1
Installation Guide
AT-OME-EX-KIT
Omega
™
4K/UHD
HDMI Over HDBaseT TX/RX with USB, Control, and PoE
AT-OME-EX-KIT
The Atlona AT-OME-EX-KIT is an HDBaseT extender for video up to 4K/60 4:2:0, plus
embedded audio, control, Ethernet, and USB 2.0 over distances up to 330 feet (100 meters).
Part of the Omega
™
Series of integration products for modern AV communications and
collaboration, the OME-EX-KIT is HDCP 2.2 compliant and extends IR, RS-232, and IP control
signals. The integrated USB extension is ideal for software video conferencing and the use of
touch or interactive displays. The OME-EX-TX transmitter includes a USB host port for a PC,
plus two peripheral devices such as a speakerphone, microphone, or keyboard and mouse. The
OME-EX-RX receiver provides two USB 2.0 interfaces for devices such as a camera or display.
The transmitter and receiver are available separately, for use with other Omega Series integration
products.*
* Both the AT-OME-EX-TX and AT-OME-EX-RX are not compatible with the AT-UHD-HDVS-300
system for extending USB.
IMPORTANT: Visit http://www.atlona.com/product/AT-OME-EX-KIT for the
latest rmware updates and User Manual.
1 x AT-OME-EX-TX
1 x AT-OME-EX-RX
2 x Captive screw connectors, 4-pin
1 x AT-IR-CS-TX
4 x Mounting plates
8 x Mounting screws
1 x 48 V DC power supply
1 x Installation Guide
Package Contents
Problemløsning Atlona AT-OME-EX-KIT
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | Netværkssender & -modtager |
| Vekselstrømsindgangsspænding: | 100 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50 - 60 Hz |
| Produktfarve: | Sort |
| Opbevaringstemperatur (T-T): | -20 - 60 °C |
| Relativ luftfugtighed ved drift (H-H): | 20 - 90 % |
| Ethernet LAN-porte (RJ-45): | 4 |
| Antal USB 2.0-porte: | 4 |
| Strømforbrug (typisk): | 32.35 W |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Certificering: | CE, RoHS, FCC |
| LED-indikatorer: | Link, Power |
| Udgangsspænding: | 48 V |
| Udgangsstrøm: | 0.83 A |
| Harmoniseret systemkode (HS): | 85176990 |
| Bæredygtighedscertifikater: | RoHS |
| Modtager bredde: | 109 mm |
| Modtager dybde: | 127 mm |
| Modtager højde: | 26 mm |
| Modtager vægt: | 870 g |
| Firmware kan opgraderes: | Ja |
| Maksimal overførselsafstand: | 100 m |
| Dataoverførselshastighed: | 120 Mbit/s |
| Understøttede kabeltyper: | Cat5e, Cat6, Cat6a, Cat7, HDMI |
| Transmitter vægt: | 406 g |
| Transmitter bredde: | 109 mm |
| Transmitter dybde: | 127 mm |
| Transmitter højde: | 26 mm |
| Antal RJ-45 porte (sender): | 2 |
| Antal RJ-45 porte (modtager): | 2 |
