Side 1/12
1
Installation Guide
AT-OME-EX-KIT-LT
Omega
™
4K/UHD
HDMI Over HDBaseT TX/RX with USB
AT-OME-EX-KIT-LT
The Atlona AT-OME-EX-KIT-LT is an HDBaseT extender for video up to 4K/60 4:2:0, plus
embedded audio, control, and USB over distances up to 130 feet (40 meters) for 4K/UHD, and up
to 230 feet (70 meters) for 1080p/60 video. Part of the Omega™ Series of integration products for
modern AV communications and collaboration, the OME-EX-KIT-LT is HDCP 2.2 compliant and
extends IR and RS-232 control signals. The integrated USB extension addresses the challenge
of connecting between USB devices at remote locations, and is ideal for software video
conferencing and touch or interactive displays. The transmitter includes a USB 2.0 host interface
for a PC, plus two peripheral devices such as a speakerphone, microphone, or keyboard and
mouse. The receiver provides two USB interfaces for devices such as a camera, soundbar, or
display.*
* Both the AT-OME-EX-TX-LT and AT-OME-EX-RX-LT are not compatible with the AT-UHD-
HDVS-300 system for extending USB.
IMPORTANT: Visit http://www.atlona.com/product/AT-OME-EX-KIT-LT for the
latest rmware updates.
1 x AT-OME-EX-TX-LT
1 x AT-OME-EX-RX-LT
2 x Captive screw connectors, 4-pin
1 x Captive screw connector, 2-pin
1 x AT-IR-CS-TX
4 x Mounting plates
8 x Mounting screws
1 x 48 V DC power supply
1 x Installation Guide
Package Contents
Problemløsning Atlona AT-OME-EX-KIT-LT
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | Netværkssender & -modtager |
| Vekselstrømsindgangsspænding: | 100 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50 - 60 Hz |
| Produktfarve: | Sort |
| Opbevaringstemperatur (T-T): | -20 - 60 °C |
| Ethernet LAN-porte (RJ-45): | 2 |
| Antal USB 2.0-porte: | 1 |
| Strømforbrug (typisk): | 30.5 W |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Kabler inkluderet: | HDMI, IR, RS-232 |
| Netværksstandarder: | IEEE 802.3af |
| LED-indikatorer: | Link, Power |
| Udgangsspænding: | 48 V |
| Udgangsstrøm: | 0.83 A |
| Harmoniseret systemkode (HS): | 85176990 |
| Bæredygtighedscertifikater: | RoHS |
| Modtager bredde: | 109 mm |
| Modtager dybde: | 127 mm |
| Modtager højde: | 26 mm |
| Modtager vægt: | 400 g |
| Firmware kan opgraderes: | Ja |
| Maksimal overførselsafstand: | 70 m |
| Dataoverførselshastighed: | 120 Mbit/s |
| Understøttede kabeltyper: | Cat5e, Cat6, Cat6a, Cat7, HDMI |
| Transmitter vægt: | 400 g |
| Transmitter bredde: | 109 mm |
| Transmitter dybde: | 127 mm |
| Transmitter højde: | 26 mm |
| Antal micro-USB 2.0-porte: | 1 |
| Strømforbrug (modtager) (maks): | 17 W |
| Strømforbrug (sender) (maks): | 13.5 W |
| Relativ fugtighed (sender): | 20 - 90 % |
| Antal RJ-45 porte (sender): | 1 |
| Antal RJ-45 porte (modtager): | 1 |
