ATS-1050 Quick Start Guide
Supplied items
Before assembling and connecting, make sure you have received all of the following items.
If anything is missing, please call 888-892-6242, 8AM to 5PM PST Monday through Friday.
Placement
© 2015 Yamaha Corporation Printed in Indonesia ZR10560
Place the sound bar in front of or below your TV, at least 50 mm
(2") away from your TV.
The sound bar may also be attached to a wall, using the
included mounting template and commercially available
screws. Refer to the Owner’s Manual for additional installation
instructions.
Set the installation position selector switch according to
the installation position of the sound bar. The sound quality
appropriate to the installation position will be set.
NOTE
•
Be careful not to stack the sound bar with any other components, as
vibration may cause system disruption in other components.
Sound bar (ATS-1050)
Mounting template
(Use when attaching the sound bar to a wall.)
Remote control Optical cable
1.5 m (4.9 ft)
3.5 mm stereo mini plug cable
1.5 m (4.9 ft)
Owner’s Manual
Continued to the reverse side
Battery
(AAA, R03, UM4) × 2
(Install the batteries in the
remote control.)
Spacer × 2
(Use when attaching the
sound bar to a wall.)
Quick Start Guide
(This sheet)
Installation position
selector switch
(bottom panel)
On a TV cabinet, etc. Attaching to a wall
Remote control
sensor (front panel)
Remote control
sensor (top panel)
Keys
Installation position
selector switch
(bottom panel)
Problemløsning Yamaha ATS-1050
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 890 mm |
| Dybde: | 131 mm |
| Højde: | 59 mm |
| Produktfarve: | Sort |
| Wi-Fi: | Ingen |
| Bluetooth: | Ja |
| Udgangseffekt (RMS): | 120 W |
| Lyddekodere: | Dolby Digital, Dolby Pro Logic II |
| Understøttelse af Smartphone-fjernbetjening: | Ja |
| Understøttede lydformater: | AAC, SBC |
| Strømforbrug (standby): | 0.4 W |
| Strømforbrug (typisk): | 22 W |
| Bluetooth-version: | 2.1+EDR |
| Forbindelsesteknologi: | Kabel & trådløs |
| Lyd-output kanaler: | 2.1 kanaler |
| Kan monteres på væggen: | Ja |
| Antal drivere til diskant: | 2 |
| Lyd (L, R) indgang: | 1 |
| Diskant diameter: | 19 mm |
| Mid-range driver diameter: | 55 mm |
| Subwoofer RMS-effekt: | 60 W |
| Subwoofer inkluderet: | Ja |
| Subwoofer placering: | Indbygget |
| Soundbar-højttaler RMS-effekt: | 60 W |
| Soundbar vægt: | 4000 g |
| Digital lyd koaksial indgang: | 1 |
| Subwoofer frekvensomrpde: | 55 - 160 Hz |
| Digital akustisk og optisk indgang: | 1 |
| Basrefleks: | Ja |
| Antal mellemtoneenheder: | 2 |
| Subwoofer-impedans: | 3 ohm (Ω) |
| Woofer diameter (subwoofer): | 3 " |
| Diskant impedans: | 4 ohm (Ω) |
