EN
Quick guide
* Available only on certain models
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance, please
register your product on www . whirlpool . eu/ register
Before using the appliance carefully read the Safety
Instruction.
FIRST TIME USE
After installation, wait at least two hours before connecting the
appliance to the power supply. Once connected, it will start working
automatically. The ideal temperature settings are preset from the
factory.
After turning the appliance on, wait 4-6 hours for it to reach the correct
food storage temperature.
CONTROL PANEL
1. On/o
2. Fridge temperature indicator
3. Fridge temperature setting
4. Fast freeze indicator light
5. Fast freeze button (rapid freezing)
ON/OFF
The whole product (both fridge and freezer compartments) can be
turned on by pressing this button for 2 seconds. The last set value is
indicated on the interface. Press this button to turn o the device.
FRIDGE TEMPERATURE INDICATOR LIGHT
It shows the temperature of the fridge compartment.
FRIDGE TEMPERATURE SETTING
It allows you to change the fridge temperature value, in a cyclical way;
it also conrms the selected temperature on the interface.
Recommended setting for the refrigerator compartment is +4°C.
FAST FREEZE INDICATOR LIGHT
lluminates when the Fast freeze button is pressed.
FAST FREEZE FUNCTION
This function is recommended for freezing fresh food. Fresh food
should be frozen as quickly as possible, for the best possible
preservation and for keeping its nutritional value. Press the Fast freeze
button when you need to freeze fresh food; the Fast freeze indicator
will come on.
We recommend you press the Fast freeze button 24 hours before
putting the food in, in order to prepare the freezer compartment for
the best possible freezing conditions. We recommend you use the
bottom drawer to maximize the freezing capacity.
The Fast freeze function is automatically deactivated after 48 hours, or
you can disable it manually by pressing the Fast freeze button.
LED LIGHT
This product contains a light source of energy eciency class F.
If the LED light system does not work, please contact the Service to
replace it.
Important: The refrigerator compartment light switches on when
the refrigerator door is opened. If the door is kept open for more than
8 minutes the light will be automatically switched o.
6th SENSE
This function automatically works to ensure the optimal conditions
to preserve the stored food. The “6th Sense” function is automatically
activated when:
• a large amount of food is loaded into the refrigerator
• the refrigerator door is left open for a long time
• a prolonged power failure takes place, causing the internal
temperature of the appliance to increase to values that cannot
guarantee safe storage of food.
Problemløsning Whirlpool W7X 82I K
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 220-240 V |
| Vekselstrømsindgangsfrekvens: | 50 Hz |
| Bredde: | 596 mm |
| Dybde: | 678 mm |
| Højde: | 1912 mm |
| Vægt: | 73000 g |
| Produktfarve: | Sort |
| Lampe type: | LED |
| Indbygget skærm: | Ja |
| Strøm: | 1 A |
| Ledningslængde: | 2.45 m |
| Årligt energiforbrug: | 252 kWh |
| Placering af apparat: | Fritstående |
| Dørhængsel: | Højre |
| Tilsluttet belastning: | 160 W |
| Støjniveau: | 39 dB |
| Energieffektivitetsskala: | A til G |
| Støjemissionsklasse: | C |
| Energieffektivitetsklasse: | E |
| Vendbare døre: | Ja |
| Fryser, netto rumindhold: | 104 L |
| Frysekapacitet: | 11 kg/24t |
| Opbevaringstid under strømafbrydelse: | 17 t |
| Klimaklasse: | SN-T |
| Køleskab antal hylder/kurve: | 5 |
| Antal grøntsagsskuffer: | 1 |
| Køleskab, netto rumindhold: | 231 L |
| Total netto kapacitet: | 335 L |
| No Frost (køleskab): | Ja |
| Køleskab indvendigt lys: | Ja |
| Stjernebedømmelse: | 4* |
| Fryser position: | Bottom-placeret |
| Automatisk afrimning (fryser): | Ja |
| Hylder, materiale: | Glas |
| Ismaskine: | Ingen |
| No Frost (fryser): | Ja |
| Hurtig frys funktion: | Ja |
| Fryser antal hylder/kurve: | 3 |
| Åben dør alarm: | Ja |
| Isterning bakke: | Ja |
| Frisk zone, aflukke: | Ja |
| Automatisk afrimning (køleskab): | Ja |
| Temperaturalarm: | Ja |
| Minimal driftstemperatur: | 10 °C |
| Maksimal driftstemperatur: | 43 °C |
| Antal aftagelige hylder: | 3 |
| Dør flaskehylde: | Ja |
