Side 1/4
GB
Quick Guide
CONTROL PANEL
WASH CYCLE TABLE
THANK YOU FOR BUYING A WHIRLPOOL PRODUCT
In order to receive a more complete assistance,
please register your product on
www.whirlpool.eu/register
Before using the appliance carefully read the Safety Instruction.
Before using the machine, it is imperative that the transport bolts are removed.
For more detailed instructions on how to remove them, see the Installation Guide.
PRODUCT DESCRIPTION
1. Worktop
2. Detergent dispenser
3. Control panel
4. Door handle
5. Door
6. Water lter
7. Adjustable feet (4)
DETERGENT DISPENSER
Compartment 1: Pre-wash detergent
(powder)
Compartment 2: Washing detergent
(powder or liquid)
Compartment 3: Additives (fabric softeners,
etc.)
The fabric softener must not exceed the “MAX”
level.
! Use powder detergent for white cotton
garments, for pre-washing, and for washing at
temperatures over 60°C.
! Follow the instructions given on the detergent packaging.
1
2
3
1.
3.2.
5.
4.
6.
7.
Maximum load 9 kg
Power input in o mode 0,5 W / in left-on mode 8 W
Detergents and
additives
Recommended
detergent
Residual
dampness % (***)
Energy
consumption kWh
Total water lt
Laundry
temperature °C
Programme
Temperatures Max.
spin
speed
(rpm)
Dry-
ing
Max. load
for wash
cycle (kg)
Max. load
for drying
cycle (kg)
Duration
(h : m)
Prewash Main Softener
Powder Liquid
Setting Range 1 2 3
MIXED 40°C - 40°C 1000 9,0 6,0 ** - - – – – –
COTTON 2 40°C - 60°C 1400 9,0 6,0 3:55 - 49 1,1 95 40
SYNTHETICS 3 40°C - 60°C 1200 4,0 4,0 2:55 - 35 0,75 55 43
RAPID 30’ 30°C - 30°C 800 - 4,5 - 0:30 - - 71 0,2 45 27
20°C 20 °C - 20 °C 1400 9,0 6,0 1:50 - - 49 0,16 90 22
WASH&DRY 45’ 30°C 30°C 1400 1,0 1,0 ** - - – – – –
WASH & DRY 90’ 30°C 30°C 1200 2,0 2,0 ** - - – – – –
SPIN & DRAIN * - - 1400 9,0 6,0 ** - - - - - – – – –
RINSE & SPIN - - 1400 9,0 6,0 ** - - - - – – – –
WHITE 60°C - 90°C 1400 9,0 6,0 2:45 (90°) 49 0,9 90 55
ECO 40-60 (1) 40 °C 40°C
1351 9,0 6,0 3:40 - 53,5 0,86 54 38
1351 4,5 3,0 2:50 - 53,5 0,68 54 37
1351 2,25 - 2:10 - 53,5 0,46 40 34
WOOL 40°C - 40°C 800 2,0 2,0 ** - - – – – –
DELICATES 30°C - 30°C 0 1,0 1,0 ** - - – – – –
COLOURS 15° 15°C 15°C 1000 4,5 4,5 ** - - – – – –
Required dosage Optional dosage
ECO COTTON 4 60 °C 60 °C 1400 9,0 6,0 3:40 - 53 1,17 60 –
1. On/O button
2. Programme selector
3. Start/Pause button
4. Temperature button
5. FreshCare+ button
6. Dry Only button / Lock button
7. Drying settings button
8. Display
9. Start delay button
10. Spin speed button
21 93
4
10 6
5
7
8
DISPLAY INDICATORS
Washing phase
Indicates washing phase of the cycle
Drying phase
FreshCare+ activated
Key lock activated
Drying only
Timer drying mode
Drying automatic levels
Start delay activated
Door locked
Note: spin speed values shown on the display can slightly differs from the values stated in the table.
2) Long cotton programme: set the “ “ programme with a temperature of 40°C.
3) Synthetic program along: set the “ “ programme with a temperature of 40°C.
* Select the programme and set the spin speed to “ “ to empty only.0
** The duration of the programme is shown on the display.
***
After programme end and spinning with maximum selectable spin speed, in default
programme setting.
6th Sense - the sensor technology adapts water, energy and programme duration to your wash load.
4) Eco Cotton -
Test wash cycle in compliance with regulations 1061/2010. Set “
” wash
cycle at a temperature of 60°C to access this cycles.
For wash programmes with temperatures above 50°C, we recommend using powder detergent
rather than liquid, and following the directions given on the detergent package.
This data may dier in your home due to changing conditions in inlet water temperature,
water pressure etc. Approximate programme duration values refer to the default setting of
the programmes, without options.
The values given for programmes other than the Eco 40-60
programme are indicative only.
For all Test Institutes
1)
Eco 40-60 (Wash)- Test wash cycle in compliance with EU Ecodesign regulation 2019/2014.
The most efficient programme in terms of energy and water consumption for washing normally soiled
cotton laundry.
Eco 40-60 (Drying)-
Test wash cycle in compliance with EU Ecodesign regulation
2019/2014
. To access “wash and dry” cycle select “Eco 40-60” wash programme and set
“Drying” option leval to
“ ”.
The most ecient programme in terms of energy and water
consumption for washing and drying normally soiled cotton laundry.
(Cycle duration: Full load 9:20 / Hald load: 5:10)
Problemløsning Whirlpool BI WDWG 961484 EU
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 220-240 V |
| Vekselstrømsindgangsfrekvens: | 50 Hz |
| Bredde: | 595 mm |
| Dybde: | 545 mm |
| Højde: | 820 mm |
| Vægt: | 66000 g |
| Produktfarve: | Hvid |
| Kontroltype: | Buttons, Rotary |
| Indbygget skærm: | Ja |
| Strøm: | 10 A |
| Pakkevægt: | 68000 g |
| Pakkedybde: | 595 mm |
| Pakkebredde: | 645 mm |
| Pakkehøjde: | 890 mm |
| Placering af apparat: | Indbygget |
| Dørhængsel: | Venstre |
| Ilægningstype: | Front-læsning |
| Maksimal centrifugeringshastighed: | 1400 rpm |
| Antal vaskeprogrammer: | 14 |
| Støjniveau (centrifugering): | 70 dB |
| Støjniveau (vask): | 45 dB |
| Forsinket start-timer: | Ja |
| Vaskeprogrammer: | Cotton, Daily care, Eco, Hand/wool, Synthetics, White, Hot colour, Spin/drain |
| Børnesikring: | Ja |
| Energiforbrug ved vask: | 234 kWh |
| Tromlemateriale: | Rustfrit stål |
| Tromle volumen: | 58 L |
| Balje materiale: | Plast |
| Spin-tørre klasse: | B |
| Restfugtighed: | 53 % |
| Energieffektivitetsskala: | A til G |
| Indikator for resterende tid: | Ja |
| Støjemissionsklasse: | A |
| Visningsvindue: | Ja |
| Tørreprogrammer: | Iron dry, Cupboard dry, Cupboard dry+ |
| Tørreevne: | 6 kg |
| Vaske kapacitet: | 9 kg |
| Støjniveau (tørring): | 55 dB |
| Cyklustid vask og tørring: | 560 min. |
| Vandforbrug pr. vask: | 50 L |
| Energiforbrug pr. vask og tørring: | - kWh |
| Vandforbrug pr. vask og tørring: | 65 L |
| Tilføj tøj (pause) -funktion: | Ingen |
| Energieffektivitetsklasse (vask): | C |
| Energieffektivitetsklasse (vask og tørring): | D |
| Energiforbrug pr. 100 cyklusser (vask): | 65 kWh |
| Energiforbrug pr. 100 cyklusser (vask og tørring): | 307 kWh |
| Cyklustid vask: | 220 min. |
