AKM 260 PRODUCT DESCRIPTION SHEET
EXP
GB
5019 319 01035
Whirlpool is a registered trademark of Whirlpool USA
Operation of burners with safety
device and electric ignition
To light one of the burners:
• Press the relative knob and turn it anti-
clockwise to the large flame and star
setting .
• At the same time, keep the knob pressed
against the control panel until the burner
ignites.
• After the burner has ignited, keep the knob
pressed for about 10 seconds.
• Release the knob.
If the burner does not ignite, repeat the operations
described above.
Note:
- Should particular local conditions of the
delivered gas make the ignition of the burner
difficult, it is advisable to repeat the operation
with the knob turned to the small flame
setting .
- The safety device of the burner shuts off the gas
supply to the burner if its flame goes out
accidentally (because of a sudden gust of wind,
an interruption in the gas delivery, the
overflowing of liquids, etc.).
1. Removable panstand grids
2-3. Medium burners
4. Large burner
5. Small burner
6. Medium burner control knob
7. Medium burner control knob
8. Large burner control knob
9. Small burner control knob
Symbols
Shaded
circle
Tap closed
Large
flame
and star
Maximum opening/delivery
and electric ignition
Small
flame
Minimum opening or
reduced delivery
Problemløsning Whirlpool AKM260/IX
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vekselstrømsindgangsspænding: | 230 V |
| Bredde: | 580 mm |
| Dybde: | 500 mm |
| Højde: | 41 mm |
| Vægt: | 7500 g |
| Produktfarve: | Sølv |
| Placering af apparat: | Indbygget |
| Komfurtype: | Gaskomfur |
| Antal kogeplader / madlavningsområde: | 4 |
| Blus/kogeplade zone 1 strøm: | 3000 W |
| Blus/kogeplade zone 2 strøm: | 1650 W |
| Blus/kogeplade zone 1 type: | Stor |
| Kogezone 1 form: | Rund |
| Blus/kogeplade zone 1 position: | Venstre front |
| Blus/kogeplade zone 1 strømkilde: | Gas |
| Blus/kogeplade zone 2 type: | Regelmæssig |
| Kogezone 2 form: | Rund |
| Blus/kogeplade zone 2 position: | Venstre bagende |
| Blus/kogeplade zone 2 strømkilde: | Gas |
| Blus/kogeplade zone 3 type: | Regelmæssig |
| Blus/kogeplade zone 4 type: | Simre |
| Blus/kogeplade zone 4 strømkilde: | Gas |
| Kogezone 4 form: | Rund |
| Blus/kogeplade zone 3 strømkilde: | Gas |
| Kogezone 3 form: | Rund |
| Blus/kogeplade zone 3 position: | Højre bagende |
| Blus/kogeplade zone 4 position: | Højre forside |
| Antal gasbrændere: | 4 |
| Blus/kogeplade zone 4 strøm: | 1000 W |
| Blus/kogeplade zone 3 strøm: | 1650 W |
