Lithium Battery Brightpad Instruction
[Product Brief]
Lithium Battery Brightpad Instruction is a professional tool for making cartoons and animations, mainly
composed of acrylic light guide plates and LED light bars. When using, the copy paper and the draft are
overlapped together, you can clearly see the picture on the bottom draft, and copy or modify the painting
on the first sheet. The animator can be used to draw the decomposition action of the action (middle
picture), and the animator can be used to depict the draft as the original. In addition, it is also suitable for
beginners to learn to use.
[Caution]
2. To ensure that the life of the lithium battery will be longer, the power switch must be turned off when
charging.
3. The red indicator light indicates that it is charging, and the blue indicator light is full.
4. Under normal circumstances: 5 to 6 hours can be used after charging for 2 hours.
[Operating instructions]
[Product parameters]
Fully charge the Brightpad.1. After pressing the switch key
lightly, the copying station
starts to work. Press the key
again to adjust to the appropri-
ate brightness.
2. After placing the sketch in a
fixed area, add copy paper to
start sketching.
3. Finish drawing ,turn off the
power.
4.
Product number:
Product Size:
Light emitting area:
Life time:
Charging port:
A4-D26
339X248X19mm
309X218mm
390 minutes
Type-C Port
5V
1.88W
6500K
350/680/1000/1320/1620LUX
2500mAh
Input voltage:
Rated power:
Color temperature:
Illumination:
Battery Capacity:
5 Levles dimming that can be optional, hold down the button to adjust brightness
1. When brightness of brightpad is lower than usually , it will automatically power-of, reminding you that
it needs to be charged.
