Table of Contents Rev. 9/26/2023 H-Hoppers MANUAL
Table of Contents Copyright 2023 Vestil Manufacturing Company Page 1 of 14
H-SERIES HOPPERS
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to
determine whether it sustained damage during transport. If damage is discovered, record a
complete description of it on the bill of lading. If the product is undamaged, discard the
packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is
used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts,
labels, and accessories, call our Technical Service and Parts Department at (260) 665-7586. The
department can also be contacted online at https://www.vestil.com/page-parts-request.php.
Electronic Copies of Instruction Manuals
Additional copies of this manual may be downloaded from https://www.vestil.com/page-
manuals.php.
Table of Contents
Page
Table of Figures
Page
Specifications……………….…...… 2
2
Replacement Release Handle with Cable Kit………….
2
Signal Words….………..……….…..
3
Exploded view & bill of materials: H-25 series hoppers..
4
Safety Instructions….…....………...
3
Exploded view & bill of materials: H-33 series hoppers..
5
National Standards…………......…
11
Exploded view & bill of materials: H-50 series hoppers..
6
Loading the Chute…..….….……..
11
Exploded view & bill of materials: H-75 series hoppers..
7
Using the Hopper…………...……..
11
Exploded view & bill of materials: H-100 series hoppers
8
Stacking Hoppers……...……….....
12
Exploded view & bill of materials: H-150 series hoppers
9
Record of Satisfactory Condition
12
Exploded view & bill of materials: H-200-HD………….....
10
Inspections & Maintenance…….. =
12
Labeling Diagram………………….
13
Limited Warranty…………………..
14
Vestil Manufacturing Company
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestil.com info@vestil.com
