TABLE OF CONTENTS Rev. 3/28/2022 CBFC, MANUAL
TABLE OF CONTENTS Copyright 2022 Vestil Manufacturing Co. Page 1 of 13
CBFC Counterbalanced Floor Crane
Receiving Instructions
After delivery, remove the packaging from the product. Inspect the product closely to determine
whether it sustained damage during transport. If damage is discovered, record a complete description
of it on the bill of lading. If the product is undamaged, discard the packaging.
NOTE: The end-user is solely responsible for confirming that product design, use, and maintenance
comply with laws, regulations, codes, and mandatory standards applied where the product is used.
Technical Service & Replacement Parts
For answers to questions not addressed in these instructions and to order replacement parts, labels,
and accessories, call our Technical Service and Parts Department at (260) 665-7586. The department
can also be contacted online at http://www.vestilmfg.com/parts_info.htm
.
Electronic Copies of Instruction Manuals
Additional copies of this instruction manual may be downloaded from
https://www.vestil.com/page-
manuals.php.
V
ESTIL
M
ANUFACTURING
C
ORP
.
2999 North Wayne Street, P.O. Box 507, Angola, IN 46703
Telephone: (260) 665-7586 -or- Toll Free (800) 348-0868
Fax: (260) 665-1339
www.vestilmfg.com info@vestil.com
Table of Contents
Page
Signal Words….………………………………………………………………………………………………….
2
Safety Instructions………………………………………………..……………………………...………………
2
CBFC-500 & CBFC-1000 Exploded View & Bill of Materials……………………..………………………
3
CBFC-500 Rated Loads for Specified Boom Lengths…….………………………………………………
4
CBFC-1000 Rated Loads for Specified Boom Lengths …….……………………….……….………….
5
CBFC-2000 Exploded View & Bill of Materials………………….…..………………………..……………
6
CBFC-2000 Rated Loads for Specified Boom Lengths…………..………………………....……………
7
Manual Hydraulic Pump Exploded View & Bill of Materials.……………………………………...……
8
Operating the Manual Hydraulic Pump………………..………………………………………..…………
9
Using the Crane………………………………………………………………………...…………………….…
9
Air Purging Procedure…………………………………………………………………………………………
10
Boom Length Adjustment…………………..…………………………………………………………………
10
Record of Satisfactory Condition……………………………………………………………………………
10
Inspections & Maintenance………………………………………………………………………………….
10 - 11
Troubleshooting…………………………………………………………………………………………………
11 - 12
Labeling Diagram……...……………………………………..…………………………………………..……
12
Limited Warranty…...……………………………………………………………………………………………
13
