Side 1/4
Ethernet Cable
Extender
PGW2440
Adapter
PG2400P
Powerline
1Plug the adapter into a power outlet
and connect it to the router’s LAN
port via an Ethernet cable.
2
Tip:
Want to unify or personalize your network? See the back
page for instructions.
Plug the extender into a power outlet on the same electrical circuit.
Wait until the extender’s Powerline LED turns solid green.
Note: If the LED does not turn solid green, please refer to > .FAQ Q2
3
Connect your devices to the internet using the default SSID (network
name) and password on the label at the top of the extender.
Attention
2. Plug powerline devices into wall outlets instead of power strips.
Note: Using power strip will aect network performance or even cause connection drops.
1. Use the product only in the upright direction.
Wall Outlet Power Strip
Quick Installation Guide
Plug and Play
Router
WAN LAN
* PGW2440 KIT (European version) is used for demonstration in this guide.
* Images may dier from actual products.
SSID:TP-Link_XXXX
SSID:TP-Link_XXXX_5G
Wireless Password:XXXXXXXX
SSID:TP -LINK_XXX X
SSID:TP -LINK_XXX X_5G
Wireless P worass d:XXXX XXXX
G.hn powerline devices are not compatible with HomePlug AV/AV2 powerline devices.
On
Problemløsning TP-Link PGW2440
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Antal pr. pakke: | - stk |
| Produktfarve: | Hvid |
| Wi-Fi: | Ja |
| Relativ luftfugtighed ved drift (H-H): | 10 - 90 % |
| Ethernet LAN: | Ja |
| Wi-Fi-standarder: | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Driftstemperatur (T-T): | 0 - 40 °C |
| Ethernet LAN-datahastigheder: | 10,100,1000 Mbit/s |
| Sikkerhedsalgoritmer: | 128-bit AES, WPA-PSK, WPA2-PSK, WPA3 |
| Kabler inkluderet: | LAN (RJ-45) |
| Pakketype: | Kasse |
| Certificering: | CE, RoHS |
| Wi-Fi-bånd: | Dual-band (2,4 GHz / 5 GHz) |
| Bedste Wi-Fi standard: | Wi-Fi 6 (802.11ax) |
| Ethernet LAN-grænsefladetype: | Gigabit Ethernet |
| Netværksstandarder: | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| LED-indikatorer: | Ja |
| Mac kompabilitet: | Ja |
| Understøttede Windows-operativsystemer: | Ja |
| Understøttede Mac-operativsystemer: | Ja |
| Understøttede Linux-operativsystemer: | Ja |
| Maksimal dataoverførselshastighed: | 1428 Mbit/s |
| Antenne type: | Intern |
| Maksimal driftstilstand: | 300 m |
| Strømstik: | Type E / F |
| Indbygget stikkontakt: | Ja |
| PowerLine standard: | G.hn |
