TP-Link KE100 Brugsanvisning
Her er TP-Link KE100 (Termostat) brugervejledning. 3 sider på sprog Engelsk med en vægt på 0.4 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/3
Smart Thermostatic Radiator Valve
Quick Start Guide
Install Guide:
Scan QR code or visit
https://www.tp-link.com/support/faq/3404/
1. Set up a Kasa smart hub in the Kasa Smart app if you
haven’t already done so. You can get the app Kasa Smart
from the App Store or Google Play.
If you want to remotely control / manage the valve, you need to add a Kasa smart hub rst. You can adjust temperature manually.
After inserting the batteries, the valve is ready to use.
Rotate the valve to increase / decrease temperature.
OR
2. Use the provided cover-opener to press and hold the
SYNC/RESET button for 5 seconds to reset the valve.
3. Smart Open the Kasa Smart app, tap + and select
Thermostats. Follow the app instructions to pair the valve
and complete setup.
There are two types of valves: and .Thermostatic Manual
Kasa Smart Thermostatic Radiator Valve is only compatible with the thermostatic valve.
If your connector is , you can screw the new valve onto the radiator directly. M30 x 1.5
If not, check whether one of the provided adapters ts the connector. If your none of them t your
connector, please purchase a proper one yourself.
Thermostatic Valve Manual Valve
1. 2. Check existing valve type Check the connector type
01 / Check Compatibility
03 / Install the Valve
04 / Set Up the Valve After Install Don’t Have a Hub?
1. Install the valve rst before powering it up.
2. No need to shut o water before changing the radiator
valve. Water will not leak.
3. Avoid installing the valve in the same room where you
have installed the boiler thermostat.
4. Install the valve within range of your Kasa smart hub if you
wish to control it using the Kasa Smart app.
02 / Install Requirements
1. Unscrew the existing valve. Read the following instructions rst before installing
the new valve:
2. Screw the new valve directly (for M30 x 1.5 connector) or after installing
the proper adapter (for non-M30 x 1.5 connectors). The ▲ at the bottom
of the valve indicates the position of the display.
4. Open the battery cover and insert two AA LR6 Alkaline
batteries. Make sure the positive and negative
terminals face the correct direction.
3. Remove the cover of the valve by rotating
counterclockwise using the provided cover-opener.
*Do NOT use rechargeable batteries or 1.2V AA batteries.
M30 x 1.5
RAVL Adapter
RAV Adapter
RA Adapter
30mm
1.5mm
Vertical InstallationHorizontal Installation
SYNC/RESET
*Images may dier from your actual product.
Problemløsning TP-Link KE100
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Højde: | 84 mm |
| Brugervejledning: | Ja |
| Produktfarve: | Hvid |
| Kontroltype: | Dreje |
| Batterispænding: | 1.5 V |
| Indbygget skærm: | Ja |
| Skærmtype: | LED |
| Understøttelse af Smartphone-fjernbetjening: | Ja |
| Driftstemperatur (T-T): | 0 - 40 °C |
| Pakketype: | Kasse |
| Batterier inkluderet: | Ja |
| Materiale: | Polykarbonat |
| Børnesikring: | Ja |
| Programmerbar: | Ja |
| Fungerer med Google Assistant: | Ja |
| Fungerer med Amazon Alexa: | Ja |
| Nem at installere: | Ja |
| Diameter: | 56.5 mm |
| Fjernbetjent: | Ja |
| Batteritype: | AA |
| Trådløs forbindelse: | Ja |
| Antal understøttede batterier: | 2 |
| Understøttede mobile operativsystemer: | Android 10, Android 10.0, Android 11.0, Android 12.0, Android 5.0, Android 5.1, Android 6.0, Android 7.0, Android 7.1, Android 7.1.2, Android 8.0, Android 9.0, iOS 10.0, iOS 11.0, iOS 11.4, iOS 12, iOS 13, iOS 13.4, iOS 14, iOS 14.5, iOS 15 |
| Bæredygtighedscertifikater: | CE, RoHS, UKCA |
| Driftsfrekvens: | 868 Mhz |
| Antal produkter inkluderet: | 1 stk |
| Velegnet til indendørsbrug: | Ja |
| Batterier påkrævet: | Ja |
| Smart termostat: | Ja |
| Skruegevind: | M30 x 1.5mm |
