Information for Lot 9 of ErP (Ecodesign)
This addendum addresses European Union (EU) Ecodesign requirements for servers and storage
products. All data and ratings within this addendum are in reference only to the Supermicro product(s) in
the manual. The below information conforms to requirements laid down in Annex II of the Commission
Regulation 2019/424.
3(1)(a): See Section 1.1 of the system manual for the product type.
3(1)(b): See the title page and preface of the system manual for the trademark and
manufacturer’s address.
3(1)(c): See the title page of the system manual for product model number(s).
3(1)(d): See the serial number on the physical system to determine the year of manufacture.
3(1)(e-j): PSU Efficiency and Power Factor Value (Table) (From 80 Plus report)
PSU Model #: PWS-504P-
1R
Watts: 500W
PSU Efficiency
Power Factor
% of Rated Load
10 % 20 % 50 % 100 %
50 %
Single Output (AC-DC)
86.16%
91.84%
94.11%
92.61%
0.97
System (EUT) Efficiency in Idle State Power (Table)
Representative
Configurations
Measured Idle State
Power (W)
Calculated Idle Power
Allowance (W)
High-End Performance
Configuration
109.3
289.2
Typical Configuration
N/A
N/A
Low-End Performance
Configuration
71.7
232.5
System (EUT) Efficiency in Active State Power (Table)
Representative
Configurations
Active State
Efficiency Score
(Effserver)
Minimum Active State
Efficiency
High-End Performance
Configuration
22.2
Typical Configuration
N/A
9
Low-End Performance
Configuration
18.2
Problemløsning Supermicro SuperServer 5019P-WTR
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Tænd-/slukkontakt: | Ja |
| Vekselstrømsindgangsspænding: | 100 - 240 V |
| Vekselstrømsindgangsfrekvens: | 50 - 60 Hz |
| Bredde: | 437 mm |
| Dybde: | 650 mm |
| Højde: | 43 mm |
| Vægt: | 10890 g |
| Produktfarve: | Sort |
| Pakkevægt: | 21770 g |
| Opbevaringstemperatur (T-T): | -40 - 60 °C |
| Relativ luftfugtighed ved drift (H-H): | 8 - 90 % |
| Relativ luftfugtighed ved opbevaring (H-H): | 5 - 95 % |
| Ethernet LAN-porte (RJ-45): | 2 |
| Antal USB 2.0-porte: | 2 |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: | 2 |
| Ethernet LAN: | Ja |
| Driftstemperatur (T-T): | 10 - 35 °C |
| Ethernet LAN-datahastigheder: | 10000 Mbit/s |
| LED-indikatorer: | HDD, Network, Power, Status |
| Harmoniseret systemkode (HS): | 84714100 |
| Bæredygtighedscertifikater: | RoHS |
| Processorserie: | Intel |
| Maksimal intern hukommelse: | 768 GB |
| On-board grafikkort, model: | Aspeed AST2500 |
| Antal VGA-porte (D-sub): | 1 |
| Ethernet-grænsefladetype: | 10 Gigabit Ethernet |
| Indbygget processer: | Ingen |
| Kobber ethernet kabelteknologi: | 10GBASE-T |
| Antal blæsere: | 5 blæser(e) |
| Antal understøttede lagerdiske: | 4 |
| Kabinettype: | Stativ (1U) |
| Ventilator diameter: | 40 mm |
| Strømforsyning: | 500 W |
| Processor sokkel: | LGA 3647 (Socket P) |
| PCI Express slots version: | 3.0 |
| Fejlkorrigerende kode: | Ja |
| PCI Ekspres x8 slots: | 1 |
| PCI Express x16 slots: | 2 |
| Redundant strømforsyning: | Ja |
| Kompatibel processor serie: | Intel® Xeon® |
| Bundkort chipsæt: | Intel C622 |
| Understøttede hukommelsestyper: | DDR4-SDRAM |
| Antal SATA III-stik: | 10 |
| LAN Kontroller: | Intel X772, Intel X557 |
| Understøttede lagerdrev brugerflader: | Serial ATA III |
| BIOS-type: | AMI |
| BIOS-hukommelsesstørrelse: | 32 Mbit |
| RAID-niveauer: | 0, 1,5, 10 |
| Antal understøttede processorer: | 1 |
| Understøttede lagerdisk størrelser: | 3.5 " |
| Hot-swap HDD båse: | Ja |
| Antal DIMM-slots: | 6 |
| PC sundhedsovervågning: | CPU, FAN, Temperature |
| Understøttet RDIMM-clockhastigheder: | 2666,2133,2400 MHz |
| Antal installerede strømforsyninger: | 2 |
| Maksimal RDIMM hukommelse: | 192 GB |
