AOC-EXPX9502FXSR
The is a 2-port 10 Gigabit Ethernet card AOC-EXPX9502FXSR
with dual XFP optical output connectors designed to meet
the throughput and latency requirements of bandwidth-
hungry applications, while offering a very low power
envelope for energy efficiency. This is the ideal choice for
multi-core processors and optimized for virtualization and at
the same time it satisfies the need for storage over Ethern
by supporting iSCSI acceleration and providing advanced
features for unified storage connectivity.
Key Features
PCI Express 2.0 (2.5GT/s)•
Low-prole•
Intel• ® I/O Acceleration Technology (I/OAT)
Load Balancing on Multiple CPUs•
VMDq for Virtualized Environment•
Low-latency interrupts•
10GBASE-SR on multi-mode ber•
Support up to 300m ber cable•
iSCSI Remote Boot•
Intel• ® PROSet Utility for Windows Device Manager
Specications
Intel® 82598EB dual-port 10 Gigabit Ethernet controller •
Two XFP connectors •
PCI-E p1-x8 •
Low-prole standard form factor •
Intel® I/OAT to improve CPU utilization •
MSI-X support to minimize the overhead of interrupts and allow load balancing of •
interrupt handling between dierent CPUs/cores
Low-latency interrupts •
Optimized queues: 32 Transmit (Tx) and 64 Receive (Rx) per port •
VMDq for virtualized environments •
Advanced packet ltering (per port)•
Direct Cache Access (DCA) •
PXE 2.0 enabled through boot read-only memory (ROM)•
iSCSI boot •
Supported ber cable length up to 300 meters •
Supported OS: Windows, Linux, VMWare •
Typical power consumption: 14W (1.17A @ 12V)•
Storage temperature: -40ºC to 70ºC (-40ºF to 158ºF)•
Storage humidity: 90% non-condensing relative humidity at 35ºC•
Physical dimensions: 16.74cm (6.59in) x 6.89cm (2.71in) (LxW)•
Height of end brackets: standard – 12cm (4.725in), low-prole – 7.92cm (3.12in)•
Compliance/
Environmental
RoHS Compliant 6/6, Pb Free •
RoHS
c o m p l i a n t
Supported Platforms Support motherboards with minimum PCI-E p1-x8 slot•
Support Servers with low-prole or full-height PCI-E expansion slot•
For the most current product information, visit:
ww w.supermicro.com
Problemløsning Supermicro AOC-EXPX9502FXSR
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 68.90 mm |
| Dybde: | 167.40 mm |
| Produktfarve: | Black, Green |
| Opbevaringstemperatur (T-T): | -40 - 70 °C |
| Relativ luftfugtighed ved opbevaring (H-H): | 0 - 90 % |
| Strømforbrug (typisk): | 14 W |
| Forbindelsesteknologi: | Ledningsført |
| Udgangsspænding: | 12 V |
| Kompatible operativsystemer: | Windows, Linux, VMWare |
| Værtsgrænseflade: | PCI Express |
| Grænseflade: | Ethernet |
| Intern: | Ja |
| Maksimal dataoverførselshastighed: | 10240 Mbit/s |
| Indgangsstrøm: | 1.17 A |
| Overholdelse af branchestandarder: | RoHS 6/6 |
| Dataoverførselshastighed: | 10 Gbit/sek. |
| Kabeltype: | Ethernet controller |
| Porte, antal: | 2 |
