Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
Manual Revision: October 16, 2024
Product ID
U1-USB-ISOLATOR
Top View
Bottom View
1-Port Industrial USB 2.0 Galvanic Isolator - Up to 6000V
Port/Connector Function
1USB LED
• Solid Blue: Indicates there’s a connected to the USB Device
Isolated USB Device Port
Note: The Host Computer must detect the connected USB
Device before the LED turns on.
• O: No connected on the USB Device Isolated USB
Device Port
2Aux Power LED
• Solid Green: External power is being supplied
• O: No external power is being supplied
3
Isolated USB
Device Port
(Downstream)
• USB Type-A port. Provide up to 250mA output when not
using the optional power adapter
• USB 2.0 compliant
• Supports 1.5Mbps and 12Mbps only
4
USB Host Port
(Upstream)
• USB Type-B port
• Connect to the using the supplied Host Computer USB-B
to USB-A Cable
5DC Power Port
• (Optional) If the requires more than Isolated USB Device
250mA and less or equal than 500mA, an external Power
Supply (not included) is required
• 6V DC 2A Power Adapter Recommended
• Type M barrel plug: Ø 5.5x2.1x9.5mm. Center tip positive
6
DIN Rail
Mounting Point
• Use to secure the included DIN Rail Mounting Kit
7Guide Peg
• Helps to install the so it can be DIN Rail Mounting Kit
installed only in one way
Package Contents
• USB Isolator x 1
• 3ft (0.9m) USB-B to USB-A Cable x 1
• Adhesive Strip x 1
• DIN Rail Mounting Kit x 1
• Quick-Start Guide x 1
Requirements
For the latest manuals, product information, technical specications, and declarations of
conformance, please visit: www.StarTech.com/U1-USB-ISOLATOR
*Product may vary from image
