Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Product Diagram (ST4300USB3)
Port Function
1Power LED • is receiving power.Solid: Hub
2USB-A Ports (4) • Used to connect USB devices to the .Hub
Port Function
3Power Port • Used with the , to power the Power Adapter
Hub.
4USB-B Port (Host) • Used to connect the to the Host Computer
Hub.
Requirements
For the latest requirements, please visit ,
www.startech.com/ST4300USB3 www.startech.
com/ST4300USB3EU, www.startech.com/ST4300USB3GB
or
4 Port Black SuperSpeed USB 3.0 Hub
1
Installation
1. Connect the included power adapter to the USB hub. The power LED should light up
solid. Supplying external power is optional, however to ensure each USB port is fully
powered, connecting external power is recommended.
2. Connect the USB cable from the USB hub (type B port) to the host computer system.
NOTE: If connected to a USB 2.0 host port, the hub will only operate at USB 2.0 speeds.
3. The operating system should detect the hub immediately and automatically install it.
4. Once installation is complete, USB 1.x/2.0/3.0 devices should be able to be connected
to the hub and recognized.
Specications
Bus Interface USB 3.0
Number of Ports 4
Connectors • USB-A x 4
• USB-B x 1
• DC Power x 1
LEDs Power x 1
Maximum Data Transfer Rate USB 3.0L 5 Gbps
Enclosure Material Plastic
Power Adapter 5VDC, 2000mA, type M plug
Warning: Using an improper
power adapter may cause
damage to the HUB and any
connected devices. Ensure that
the correct adapter with a 5V
output is used.”
Operating Temperature 0°C~55°C (32°F~131°F)
Storage Temperature -20°C~85°C (-4°F~185°F)
Humidity 5%~95% RH
Dimensions 152.0mm x 59.6mm x 23.5mm
Weight 480g
2
3 4
Problemløsning StarTech.com ST4300USB3
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 68 mm |
| Dybde: | 95 mm |
| Højde: | 23 mm |
| Vægt: | 84 g |
| Brugervejledning: | Ja |
| Produktfarve: | Sort |
| Pakkevægt: | 411 g |
| Pakkedybde: | 214 mm |
| Pakkebredde: | 152 mm |
| Pakkehøjde: | 82 mm |
| Opbevaringstemperatur (T-T): | -20 - 60 °C |
| Relativ luftfugtighed ved drift (H-H): | 5 - 85 % |
| Antal USB 3.2 Gen 1 (3.1 Gen 1) type-A-porte: | 4 |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Husmateriale: | Plast |
| Kabler inkluderet: | USB |
| DC-in-stik: | Ja |
| LED-indikatorer: | Strøm |
| Strømkilde type: | Vekselstrøm |
| Udgangsspænding: | 5 V |
| Udgangsstrøm: | 2 A |
| AC-adapter inkluderet: | Ja |
| Bæredygtighedscertifikater: | CE, RoHS |
| Indgangsspænding: | 110 - 240 V |
| Værtsgrænseflade: | USB 3.2 Gen 1 (3.1 Gen 1) Type-B |
| Plug and play: | Ja |
| Overholdelse af bæredygtighed: | Ja |
| Gennemsnitstid mellem fejl (MTBF): | 24000 t |
| Strømstiktype: | Type M |
| Dataoverførselshastighed: | 5000 Mbit/s |
| Porte, antal: | 4 |
| Hot-swap: | Ja |
| Hub-grænseflader: | USB 3.2 Gen 1 (3.1 Gen 1) Type-A |
| Chipsæt: | VIA/VLI - VL811+ |
