Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: July 12, 2022
Product Diagram (ST10GSPEXNB2)
Port/LED/
Connector
Function
1 Bracket
• Secures the card to the Computer Case. The Full-
height Bracket comes pre-installed.
2 LED Indicators
• Left LED Indicator is Link Speed
• Solid Green = 10Gbps
• Solid Amber =
5Gbps/2.5Gbps/1Gbps/100Mbps/10Mbps
• Right LED Indicator is Link Status
• Solid Green = Active link
• Flashing Green = Activity
3 Ethernet Port
• Connect a Network Cable to the Network Card
• Supports
10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps/10 Mbps
For 10 Gbps speeds Cat6 or higher cable is needed
4 PCIe p1-x2 Connector • Insert into a PCI Express Slot on the Host Computer
1-Port 10GBase-T / NBase-T Ethernet Network Adapter Card - PCIe Ver 3.0 x2
Package Contents
• PCIe 10 Gbps Network Card x 2
• Low-prole Bracket x 1
• Quick-Start Guide x 1
Requirements
For the latest requirements, please visit www.startech.com/ST10GSPEXNB2
• Computer with an available PCI Express Slot (x2, x4, x8, or x16)
Installation
Install the PCI Express Card
WARNING!
Static Electricity can severely damage PCI Express Cards. Ensure that you are
adequately Grounded before you open your Computer Case or touch the PCI
Express Card. You should wear an Anti-Static Strap or use an Anti-Static Mat when
installing any computer component. If an Anti-Static Strap isn’t available, discharge
any built-up static electricity by touching a large Grounded Metal Surface for several
seconds. Only handle the PCI Express Card by its edges and don’t touch the gold
connectors.
1. Turn o the Computer and any Peripheral Devices that are connected to it (for
example, Printers, External Hard Drives, etc.).
2. Unplug the Power Cable from the back of the Computer.
3. Disconnect any Peripheral Devices that are connected to the Computer.
4. Remove the Cover from the Computer Case. Consult the documentation that came
with the Computer for details about doing this safely.
5. Locate an open PCI Express Slot and remove the corresponding Slot Cover Plate
from the back of the Computer Case. Consult the documentation that came with
the Computer for details about doing this safely. This card works in PCI Express x2,
x4, x8, or x16 Slots.
6. Gently insert the PCI Express Card into the open PCI Express Slot and fasten the
Bracket to the back of the Computer Case.
Note: If you install the PCI Express Card into a Small Form Factor or a Low-Prole
Desktop System, it may be necessary to replace the pre-installed standard Full-
Height Bracket with the included Low-Prole Bracket.
8. Return the Cover onto the Computer Case.
4
1
2
3
Problemløsning StarTech.com ST10GSPEXNB2
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 107 mm |
| Dybde: | 121 mm |
| Højde: | 22 mm |
| Vægt: | 70 g |
| Produktfarve: | Sort |
| Pakkevægt: | 120 g |
| Pakkedybde: | 145 mm |
| Pakkebredde: | 210 mm |
| Pakkehøjde: | 35 mm |
| Opbevaringstemperatur (T-T): | -10 - 70 °C |
| Ethernet LAN-porte (RJ-45): | 1 |
| Ethernet LAN: | Ja |
| Driftstemperatur (T-T): | 0 - 60 °C |
| Ethernet LAN-datahastigheder: | 10,100,1000,2500,5000,10000 Mbit/s |
| Hurtig installationsvejledning: | Ja |
| Forbindelsesteknologi: | Ledningsført |
| Kabelteknologi: | 10GBase-T |
| Netværksstandarder: | IEEE 1588, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3u |
| LED-indikatorer: | Ja |
| Understøttede Windows-operativsystemer: | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64 |
| Understøttede Linux-operativsystemer: | Ja |
| Hovedkassen højde (udvendigt): | 320 mm |
| Hovedkassens længde (udvendigt): | 375 mm |
| Hovedkassens bredde (udvendigt): | 445 mm |
| Værtsgrænseflade: | PCIe |
| Grænseflade: | Ethernet |
| Intern: | Ja |
| Maksimal dataoverførselshastighed: | 10000 Mbit/s |
| Produkter pr. hovedkasse (udvendigt): | 40 stk |
| Fuld duplex: | Ja |
| Ethernet-grænsefladetype: | 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet |
| Komponent til: | PC |
| Monteringsbeslag inkluderet: | Ja |
| Jumbo Frames support: | Ja |
| Jumbo rammer: | 16000 |
| Auto MDIX IEEE: | Ja |
| Output-grænseflade: | RJ-45 |
| PCI-kort formfaktor: | Fuld højde (lav profil) |
| PCI version: | 3.0 |
| Hostinterface han/kun: | Hanstik |
