Instruction Manual
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
I T: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
P T: Guia do usuário - pt.startech.com
Manual Revision: 03/12/2014
For the most up-to-date information, please visit: www.startech.com
Packaging Contents
• 1x SDI to HDMI Adapter
• 1x Mounting bracket assembly (attached)
• 1x Universal Power Adapter (NA/UK/EU/)
• 1x Instruction manual
System Requirements
• SDI video source (Security camera, broadcasting equipment Etc.)
• HDMI Display Device (e.g. Projector/Television Etc.)
• M/M HDMI Video Cable
• Up to 2 SDI M/M Video Cables
SDI2HD
SDI to HDMI® Converter w/ 3G-SDI Support
Installation
1. Ensure your SDI source device and HDMI display device are
powered o.
2. Connect the SDI input on the SDI2HD to the SDI output port on
your SDI source device using an SDI video cable (not included).
3. Connect each of the HDMI output on the SDI2HD to HDMI input
on the HDMI Display device.
4. Power on the HDMI display device followed by your SDI
video source.
5. (optional) If you would like to run your SDI source to an additional
SDI device. Run an SDI cable from the SDI output on the SDI2HD
to your SDI device.
Product Overview
Front View
Side 1
Side 2
Power adapter
port
HDMI
output
SDI input SDI output
Note: The SDI adapter will not work on devices with resolution
outputs 480p or lower, such as DVD players.
Problemløsning StarTech.com SDI2HD
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 100 mm |
| Dybde: | 70 mm |
| Højde: | 25 mm |
| Vægt: | 202 g |
| Antal pr. pakke: | 1 stk |
| Produktfarve: | Sort |
| Pakkevægt: | 492 g |
| Pakkedybde: | 152 mm |
| Pakkebredde: | 215 mm |
| Pakkehøjde: | 52 mm |
| Opbevaringstemperatur (T-T): | -10 - 60 °C |
| Driftstemperatur (T-T): | 0 - 40 °C |
| Maksimal opløsning: | 1920 x 1080 pixel |
| Udgangsspænding: | 5 V |
| AC-adapter inkluderet: | Ja |
| Harmoniseret systemkode (HS): | 84733080 |
| Bæredygtighedscertifikater: | RoHS |
| Indgangsspænding: | 100 - 240 V |
| Stik 1: | HDMI |
| Stik 2: | 2xSDI(BNC) |
| Dataoverførselshastighed: | 1.485 Gbit/sek. |
| Relativ luftfugtighed: | 5 - 90 % |
| Udgående strøm: | 2000 mA |
