Manual Revision: 02/11/2015
For the most up-to-date information, please visit: www.startech.com
Quick Install Guide
Packaging Contents
• 1 x USB 3.0 rugged 2.5in enclosure
• 1 x USB 3.0 cable
• 1 x Foam pad for 7mm drives
• 1 x Quick install guide
System Requirements
• Computer system with available USB port
• 1x 2.5in SATA Hard drive (HDD) or Solid State Drive (SSD)
Note: StarTech.com recommends using this enclosure with an
SSD to maximize drop protection in rugged environments.
S251BRU33
USB 3.0 rugged 2.5in SSD/HDD enclosure with UASP
*actual product may vary from photos
Product Overview
Hardware Installation
WARNING! Hard drives and storage enclosures require careful
handling, especially when being transported. If you are not careful
with your hard disk, lost data may result. Always handle your hard
drive and storage device with caution. Be sure that you are properly
grounded by wearing an anti-static strap when handling computer
components or discharge yourself of any static electricity build-up
by touching a large grounded metal surface (such as the computer
case) for several seconds.
1. Remove the protective sleeve from the casing, by grasping a
corner and peeling it away from the casing.
2. Grasp drive latch and pull it away from the casing to unlock the
drive door.
1. Protective casing
2. Protective sleeve
3. USB 3.0 port cover
4. USB 3.0 port
Problemløsning StarTech.com S251BRU33
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Kode for international beskyttelse (IP): | IP54 |
| Bredde: | 112 mm |
| Dybde: | 143 mm |
| Højde: | 29 mm |
| Vægt: | 265 g |
| Brugervejledning: | Ja |
| Produktfarve: | Sort |
| Produkttype: | HDD/SSD kabinet |
| Pakkevægt: | 402 g |
| Pakkedybde: | 183 mm |
| Pakkebredde: | 139 mm |
| Pakkehøjde: | 57 mm |
| Opbevaringstemperatur (T-T): | -40 - 85 °C |
| Relativ luftfugtighed ved drift (H-H): | 20 - 95 % |
| Driftstemperatur (T-T): | -40 - 85 °C |
| Kabler inkluderet: | USB |
| Certificering: | CE, FCC, REACH |
| LED-indikatorer: | Ja |
| Strømkilde type: | USB |
| Harmoniseret systemkode (HS): | 84733080 |
| USB-tilslutning: | Ja |
| USB version: | 3.2 Gen 1 (3.1 Gen 1) |
| Antal USB-porte: | 1 |
| Bæredygtighedscertifikater: | RoHS |
| Plug and play: | Ja |
| USB-stik type: | Micro-USB B |
| Overholdelse af branchestandarder: | MIL-STD-810G, Method 503.5, MIL-STD-810G, Method 514.6, MIL-STD-810G, Method 516.6, MIL-STD-810G, Method 507.5, MIL-STD-810G, Method 509.5, MIL-STD-810G, Method 510.5, MIL-STD-810G, Method 508.6 |
| Størrelse på lagerdisk: | 2.5 " |
| Antal understøttede lagerdiske: | 1 |
| Dataoverførselshastighed: | 5 Gbit/sek. |
| Maksimal lagerkapacitet: | 2 TB |
| Understøttede lagerdrev brugerflader: | SATA |
| Hot-swap: | Ja |
| Understøtter UASP: | Ja |
| Chipsæt: | ASMedia - ASM1153E |
| USB-stik køn: | Hunstik |
| Understøttede lagerdisk højder: | 7, 9.5 mm |
