Quick-start guide
FR: Guide de l’utilisateur - fr.startech.com
DE: Bedienungsanleitung - de.startech.com
ES: Guía del usuario - es.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
IT: Guida per l’uso - it.startech.com
Manual Revision: 07/15/2016
For the latest information, technical specications, and support for
this product, please visit www.StarTech.com/PEX10000SRI.
Package contents
• 1 x 10G SFP+ ber network card
• 1 x 10GBase-SR SFP+ transceiver module (preinstalled)
• 1 x low-prole bracket
• 1 x quick-start guide
System requirements
• PCI Express® enabled computer with an available PCI Express slot
(x8 or x16)
• Any of the following operating systems:
• Windows® 10 (32-bit and 64-bit)
• Windows 8.1 (32-bit and 64-bit)
• Windows 8 (32-bit and 64-bit)
• Windows 7 (32-bit and 64-bit)
• Windows Server® 2008 R2
• Windows Server 2012
• Linux® Kernel 2.6.24 and later
• Microsoft® Hyper-V®
• Phillips head screwdriver (optional)
System requirements are subject to change. For the latest
requirements, please visit www.StarTech.com/PEX10000SRI.
PEX10000SRI
1-Port 10G SFP+ Fiber Optic Network Card - PCIe - Intel Chip - MM
Introduction
To experience reliable high-performance network connectivity over
multi-mode ber, you can use the PEX10000SRI to add a 10GBase-SR
port to your server or workstation. This SFP+ network card oers up
to 10Gbps of network speed and features the Intel® 82599 chipset.
The PEX10000SRI can be mounted in both low-prole and full-prole
computer systems.
Product diagram
SFP+ slot
Link or activity LED
Mounting bracket
(full-prole pictured)
PCIe p1-x8
connector
*actual product may vary from photos
Bracket screw
Bracket screw
Install the low-prole bracket
The PEX10000SRI can be mounted in both low-prole and
full-prole computer systems. The full-prole bracket comes
preinstalled, but you can install the low-prole bracket instead.
1. Remove the 10GBase-SR SFP+ transceiver module from the
SFP+ slot on the SFP+ network card.
2. Use a Phillips head screwdriver to remove the two bracket screws
from the PEX10000SRI.
3. Remove the full-prole bracket from the SFP+ network card.
4. Line up the low-prole bracket with the bracket holes on the back
of the SFP+ network card.
5. Insert the two bracket screws that you removed in step 2 and
tighten them into place.
6. Insert the 10GBase-SR SFP+ transceiver module into the SFP+
slot on the network card
Install the network card in a computer
Warning! PC components can be severely damaged by static
electricity. If an anti-static strap isn’t available, discharge any built-
up static electricity by touching a large, grounded metal surface for
several seconds.
1. Turn o your computer and any devices or peripherals that are
connected to it (for example, printers, external storage, and
so on).
10GBase-SR SFP+
transceiver module
Problemløsning StarTech.com PEX10000SRI
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 18 mm |
| Dybde: | 135 mm |
| Højde: | 120 mm |
| Vægt: | 116 g |
| Produktfarve: | Sort |
| Pakkevægt: | 194 g |
| Pakkedybde: | 170 mm |
| Pakkebredde: | 143 mm |
| Pakkehøjde: | 30 mm |
| Opbevaringstemperatur (T-T): | -20 - 60 °C |
| Relativ luftfugtighed ved drift (H-H): | 20 - 80 % |
| Driftstemperatur (T-T): | 5 - 50 °C |
| Hurtig installationsvejledning: | Ja |
| Forbindelsesteknologi: | Ledningsført |
| Certificering: | CE, FCC, REACH |
| Netværksstandarder: | IEEE 802.1Q, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3x |
| Harmoniseret systemkode (HS): | 85176990 |
| Bæredygtighedscertifikater: | RoHS |
| Understøttede Linux-operativsystemer: | Ja |
| Værtsgrænseflade: | PCI Express |
| Grænseflade: | Fiber |
| Intern: | Ja |
| Maksimal dataoverførselshastighed: | 20000 Mbit/s |
| Fiber optisk strømstik: | SFP+ |
| Fuld duplex: | Ja |
| Komponent til: | PC |
| Understøttede operativsystemer til servere: | Windows Server 2008 R2, Windows Server 2012, Windows Server 2012 R2, Windows Server 2016, Windows Server 2019 |
| Monteringsbeslag inkluderet: | Ja |
| Flowkontrol support: | Ja |
| Jumbo Frames support: | Ja |
| Jumbo rammer: | 15000 |
| Fiberkanal porte: | 1 |
| VLAN mærkning: | Ja |
| Simpelt beslag: | Ja |
| Chipsæt: | Intel® 82599 |
