Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
Manual Revision: March 15, 2023
Product Diagram (NANOK-LAPTOP-LOCK)
Components Function
1 Lock Tip
• Used to connect the Laptop Lock to a
compatible Nano Lock Slot
2 Bumper Spacers
• Prevents the Lock from scung the connected
Device
3
Lock and
Push-To-Lock Button
• Use to Lock and Unlock the Laptop Lock with
the Keys
Note Press the Push-To-Lock Button engages
the locking mechanism without a Key
4 Security Cable
• Used to secure a Device to a secure stationary
object
• Pivots 90° and allows to rotate the Lock Head
360° around the ball-joint
Keyed Laptop Lock - Nano Lock - 6.6ft (2m)
Requirements
For the latest manuals, product information, technical specications, and declarations of
conformance, please visit: www.startech.com/NANOK-LAPTOP-LOCK
• Compatible device with Nano slot
Package Contents
• Laptop Security Lock x 1
• Keys x 2
• Hook-and-loop Strap x 1
• Quick-Start Guide x 1
Securing a Device
Note The Key is required to unlock the Laptop Lock. The availability of the Key(s)
should be known before using the Push-To-Lock Button.
1. Wrap the Security Cable around a secure stationary object (i.e., a desk leg or table
frame). Pull the Lock Head through the Loop at the end of the Security Cable.
(Figure 1).
Figure 1
2. Insert the Lock Tip into the Nano Slot of a compatible Device.
3. Press the Push-To-Lock Button. Alternatively, insert the Key into the Lock. Push
and turn the Key clockwise to engage the locking mechanism.
Unlocking a Device
1. Insert the Key into the Lock. Turn the Key counter-clockwise.
2. Pull the Lock Tip out of the Nano Slot.
3. Remove the Key from the Lock.
3
1
4
2
*Product may vary from image
Problemløsning StarTech.com NANOK-LAPTOP-LOCK
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 12 mm |
| Højde: | 23 mm |
| Vægt: | 140 g |
| Antal pr. pakke: | 1 stk |
| Brugervejledning: | Ja |
| Produktfarve: | Sort, sølv |
| Pakkevægt: | 140 g |
| Pakkedybde: | 128 mm |
| Pakkebredde: | 205 mm |
| Pakkehøjde: | 10 mm |
| Materiale: | Plastic, Steel, Zinc |
| Kabellængde: | 2 m |
| Hovedkassen højde (udvendigt): | 258 mm |
| Hovedkassens længde (udvendigt): | 238 mm |
| Hovedkassens bredde (udvendigt): | 515 mm |
| Kabellåseslids type: | Nano |
| Produkter pr. hovedkasse (udvendigt): | 50 stk |
| Kapabilitet: | EliteBook/LenovoX1/2-1 Laptop |
| Låsetype: | 2 nøgler |
| Bedste anvendelsesmuligheder: | Laptop |
| Belægning: | PVC |
| Antal udleverede nøgler: | 2 |
| Velcro kabelrem: | Ja |
