Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: July 19, 2022
Product Diagram (ICUSB232DB25)
Port/LED/
Connector
Function
1 Serial Port DB-9 • Connect Serial Peripheral Devices
2 USB Type A Port
• Connect the USB to Serial Adapter Cable to a Host
Computer
3
Serial Port DB-25
(Adapter)
• Connect a DB-25 Serial Peripheral Devices
4
Serial Port DB-9
(Adapter)
• Connect the DB9 to DB25 Serial Adapter to the USB
to RS232 Cable’s Serial DB-9 Port
1 Port USB to RS232 Serial DB9/DB25 Adapter Cable - M/M
Package Contents
• 3ft USB to RS232 Cable x1
• DB9 to DB25 Serial Adapter x 1
• Quick-Start Guide x1
Requirements
For the latest requirements, please visit: www.StarTech.com/ICUSB232DB25
• Computer with an available USB Type-A port
Installation
Install the Driver
1. Navigate to: www.StarTech.com/ICUSB232DB25
2. Click the Drivers/Downloads tab.
3. Under Driver(s), download the Driver Package for your operating system.
Windows
1. Right-click the downloaded le and extract the contents with Extract All.
2. Browse the Windows folder and run the Setup le.
3. Follow the on-screen instructions to complete the installation.
4. Connect the USB to Serial Adapter Cable to an available USB port.
macOS
1. Double-click the downloaded le.
2. Open the folder that matches your macOS Version and run the Setup le inside the
folder.
3. Follow the on-screen instructions to complete the installation.
4. Connect the USB to Serial Adapter Cable to an available USB port.
1
2
3
4
Problemløsning StarTech.com ICUSB232DB25
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Vægt: | 70 g |
| Brugervejledning: | Ja |
| Produktfarve: | Grå |
| Pakkevægt: | 143 g |
| Pakkedybde: | 172 mm |
| Pakkebredde: | 143 mm |
| Pakkehøjde: | 32 mm |
| Opbevaringstemperatur (T-T): | -40 - 85 °C |
| Driftstemperatur (T-T): | 0 - 70 °C |
| Husmateriale: | Plast |
| Certificering: | CE |
| Kabellængde: | 0.9 m |
| Harmoniseret systemkode (HS): | 84733080 |
| Bæredygtighedscertifikater: | RoHS |
| Kompatible operativsystemer: | - Windows PocketPC 2003 / 2000, Windows Mobile 5/6, CE 4.2/5.2, Embedded System 2009, XP Embedded, POS Ready 2009, 98SE, 2000, ME, XP, Vista, 7, 8, 8.1, 10\n- Windows Server 2003, 2008 R2, 2012, 2016, 2019\n- Mac OS X 10.6 - 10.14\n- Linux 2.4.x to 4.11.x LTS |
| Understøttede Mac-operativsystemer: | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.15 Catalina, Mac OS X 10.6 Snow Leopard, Mac OS X 10.7 Lion, Mac OS X 10.7.5 Lion, Mac OS X 10.8 Mountain Lion, Mac OS X 10.9 Mavericks, Mac OS X 11.0 Big Sur, Mac OS X 12.0 Monterey, Mac OS X 13.0 Ventura |
| Understøttede Linux-operativsystemer: | Ja |
| Hovedkassen højde (udvendigt): | 405 mm |
| Hovedkassens længde (udvendigt): | 466 mm |
| Hovedkassens bredde (udvendigt): | 282 mm |
| Drivere inkluderet: | Ja |
| Produkter pr. hovedkasse (udvendigt): | 50 stk |
| Overholdelse af bæredygtighed: | Ja |
| Understøttede operativsystemer til servere: | Windows Server 2003, Windows Server 2008 R2, Windows Server 2012, Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Stik 1: | USB 2.0 |
| Stik 2: | DB-25 + DB-9 |
| Stik 1 køn: | Hanstik |
| Stik 2 køn: | Hanstik |
| Baud hastighed: | 230.4 Kbit/s |
| Data-bits: | 4, 5,6, 7,8 |
| Stop bits: | 1, 1.5, 2 |
| Relativ luftfugtighed: | 5 - 85 % |
| Chipsæt: | Prolific - PL-2303 |
| FIFO (først ind, først ud): | 512 B |
| Flow Control type: | N, XON/XOFF |
| Paritetsbit: | Even, Mark, N,Odd, Space |
