Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: January 14, 2021
7
6
11
9
*CTK55PCEDRIVE
1
5
3
4
2
*CTK55PCEDRIVE
Product Diagram (CTKxxPCEDRIVE)
Package Contents
Bit Extender, Storage Tube, and Electric Screwdriver
Port Function
1 Case
• Holds the Bits, Demagnetizing Tool, and the Storage
Tube containing the Electric Screwdriver
• CTK20PCEDRIVE features a Soft-shell Case
2 AAA Batteries x 2 • 3V DC AAA Batteries
20/55-bit Precision Electric Screwdriver with Alkaline Battery
3 Demagnetizing Tool
• Magnetize Bits
• Move the Bit around the inside of the square
portion of the Demagnetizing Tool
• Demagnetize Bits
• Move the Bit around the inside of the U-shaped
portion of the Demagnetizing Tool
4
20 Bits
(CTK20PCEDRIVE)
55 Bits
(CTK55PCEDRIVE)
CTK20PCEDRIVE:
H4X28 x 20 Pieces
Philips (PH000, PH00, PH0, PH1)
Slot/Flat (SL1.0, SL1.5, SL2.0)
TORX (T5)
TORX Security (T6, T8)
Hexagonal (H2.5, H3.0)
Pentalobe (P2(0.8), P5(1.2), P6(1.5))
Spanner (U3.0)
TriWing (Y0.6, Y2.5)
Triangle (Δ3.0)
Square/Robertson (S0)
CTK55PCEDRIVE:
H4X28 x 50 Pieces
Philips (PH0000, PH000, PH00, PH0, PH1, PH2)
Hexagonal (H0.7, H0.9, H1.3, H1.5, H2.0, H2.5, H3.0, H3.5,
H4.0)
Slot/Flat (SL1.0, SL1.5, SL2.0, SL2.5, SL3.0, SL3.5)
TORX (T2, T3, T4, T5)
TORX Security (T6, T7, T8, T9, T10, T15, T20)
Triangle (Δ2.0, Δ2.3, Δ2.5, Δ3.0)
TriWing (Y0.6, Y1.0, Y2.0, Y2.5, Y3.0)
Spanner (U2.0, U2.6, U3.0)
Pentalobe (P2(0.8), P5(1.2), P6(1.5))
Square/Robertson (S0, S1, S2)
H4X45 x 5 Micro Pieces
Philips (PH0, PH2)
Hexagonal (H2.0, H2.5)
Slot/Flat (SL2.5)
5
Magnetic Work Pad
(CTK55PCEDRIVE
only)
• Holds magnetized Bits and Screws
6
Bit Extender
(CTK55PCEDRIVE
only)
• Insert into the Electric Screwdriver to extend the Bits
7
Storage Tube
(CTK55PCEDRIVE
only)
• Storage Tube for the Electric Screwdriver
8
10
Problemløsning StarTech.com CTK20PCEDRIVE
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Bredde: | 16 mm |
| Dybde: | 180 mm |
| Højde: | 16 mm |
| Vægt: | 250 g |
| Produktfarve: | Sølv |
| Produkttype: | Skruemaskine |
| Pakkevægt: | 250 g |
| Pakkedybde: | 113 mm |
| Pakkebredde: | 250 mm |
| Pakkehøjde: | 43 mm |
| Batteriteknologi: | Alkaline |
| Strømkilde: | Batteri |
| Tomgang (maks.): | 110 rpm |
| Bæredygtighedscertifikater: | CE, RoHS |
| Numre af batterier medfølger: | 2 stk |
| Hovedkassen højde (udvendigt): | 415 mm |
| Hovedkassens længde (udvendigt): | 495 mm |
| Hovedkassens bredde (udvendigt): | 255 mm |
| Længde: | 180 mm |
| Produkter pr. hovedkasse (udvendigt): | 55 stk |
| Maksimal torsion: | 0.35 Nm |
| Batteri medfølger: | Ja |
| Håndtagsform: | Lige håndtag |
| Antal bits: | 20 stk |
| Skruetrækker/bits tippe inkluderet: | Pentalobe, Phillips, Robertson, Slot, Spanner, Torx, Tri-Wing, Triangle |
