Quick-Start Guide
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.
Manual Revision: April 21, 2022 2:00 PM
Transmitter
Side A Side B
Product ID
C15012-USB-EXTENDER
1-Port USB 2.0 Over Cat5/Cat6 Extender - 490 ft. (150 m)
Component Function
1
USB-B Host Port
(Transmitter)
• Connect to a USB-A Port on a Host
Computer
• USB 2.0 (480 Mbps)
2
RJ-45 Output
(Transmitter)
• Connect the Transmitter to the Receiver
using a Cat5e/Cat6 Cable
Product Diagram
1
3
DC 5V Power Port
(Transmitter)
*NOT REQUIRED
• Used to connect the Transmitter to a Power
Source. A local power source is not required,
as the Transmitter is powered by the USB
Host Computer
4
Power LED
(Transmitter)
• Indicates if the Transmitter is receiving
power
• Solid Green = Receiving Power
• O = Not Receiving Power
5
USB-A Peripheral Port
(Receiver)
• Connect a Remote USB-A Peripheral
• USB 2.0 (480Mbps)
• Supports up to 5 V/0.5 A (2.5 W) Power
6
RJ-45 Input
(Receiver)
• Connect the Receiver to the Transmitter
using a Cat5e/Cat6 Cable
7
DC 5V Power Port
(Receiver)
• Connect the Receiver to a Power Source,
using the Universal Power Adapter
8
Power LED
(Receiver)
• Indicates if the Receiver is receiving power
• Solid Green = Receiving Power
• O = Not Receiving Power
Package Contents
• USB Over Cat5/Cat6 Transmitter x 1
• USB Over Cat5/Cat6 Receiver x 1
• 2 ft (61 cm) USB-A to USB-B Host Cable x 1
• Universal Power Adapter (North America) x 1
Requirements
• Computer (local) with a USB-A Port
• USB peripheral device (remote) with Required Cabling
• Cat5/Cat6 Cabling. Up to 490 ft (150 m)
For the latest drivers, manuals, product information, technical specications, and
declarations of conformance, please visit:
www.StarTech.com/C15012-USB-EXTENDER
Receiver
2
3
4
Side A Side B
5 6
7
8
Problemløsning StarTech.com C15012-USB-EXTENDER
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Type: | Konsol sender & modtager |
| Bredde: | 67 mm |
| Dybde: | 32 mm |
| Højde: | 25 mm |
| Vægt: | 173 g |
| Produktfarve: | Sort |
| Pakkevægt: | 173 g |
| Pakkedybde: | 194 mm |
| Pakkebredde: | 220 mm |
| Pakkehøjde: | 60 mm |
| Opbevaringstemperatur (T-T): | -20 - 70 °C |
| Relativ luftfugtighed ved drift (H-H): | 10 - 90 % |
| Strømforbrug (typisk): | 15 W |
| Driftstemperatur (T-T): | 0 - 50 °C |
| Husmateriale: | Metal |
| Kabler inkluderet: | USB Type-A til USB Type-B |
| DC-in-stik: | Ja |
| LED-indikatorer: | Strøm |
| Strømkilde type: | DC |
| Udgangsspænding: | 5 V |
| Udgangsstrøm: | 3 A |
| AC-adapter inkluderet: | Ja |
| Bæredygtighedscertifikater: | CE, RoHS |
| Indgangsspænding: | 100 - 240 V |
| Hovedkassen højde (udvendigt): | 278 mm |
| Hovedkassens længde (udvendigt): | 400 mm |
| Hovedkassens bredde (udvendigt): | 400 mm |
| Plug and play: | Ja |
| Indgangsstrøm: | 0.6 A |
| Maksimal overførselsafstand: | 150 m |
| Produkter pr. hovedkasse (udvendigt): | 12 stk |
| Strømstiktype: | Type H |
| Antal RJ-45-porte: | 2 |
| Dataoverførselshastighed: | 480 Mbit/s |
| Antal USB 2.0 Type-B porte: | 1 |
| Understøttede kabeltyper: | Cat5e, Cat6 |
| Antal USB 2.0 type-A-porte: | 1 |
