WAT10 / WAT10W / WAT50 / WAT50W 70/25V In-Wall Volume Control
Thank you for your choice of one of Speco Technologies’ WAT volume controls. This unit is designed to provide a sturdy and
reliable option to control volume in rooms in commercial installations away from the main amplifier.
FEATURES
• 9 volume steps plus off position
• Fit in a standard single gang, high cube junction box
• Set screw wire connection
• Accepts up to 12 gauge wire
• Mono sound
• Either stainless steel or white plastic plate with plastic knob.
• Dimensions: 2 ¼” (W) x 4 ½” (H) x 1 ⅝” (D)
INSTALLATION VIEW
SPECIFICATIONS
Part Number Sound Wattage Output Plate / Knob Color
WAT10 Mono 10 70/25V Silver / Black
WAT10W Mono 10 70/25V White / White
WAT50 Mono 50 70/25V Silver / Black
WAT50W Mono 50 70/25V White / White
Speco Technologies is constantly developing and improving products.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
Speco Technologies . 200 New Highway . Amityville . NY . 11701 . www.specotech.com
Rev. 04/21/20
