Optional Accessory
Specications
Image Sensor ................... 1/3” 960H CCD
Resolution......................... 700 TV lines
Minimum Illumination ........ 0.01 lux, 0 lux with IR on
Effective Pixels ................. 976 (H) x 494 (V)
Number of IR LEDs .......... VLEDT1HG/VLEDT1HW: 36
VLEDT2HG/VLEDT2HW: 24
IR Range .......................... VLEDT1HG/VLEDT1HW:
Up to 98’ (depending on scene reection)
VLEDT2HG/VLEDT2HW:
Up to 65’ (depending on scene reection)
IR LED Wavelength .......... 850nm
IR Status ........................... IR on: under 10 lux, by CDS auto control
Electronic Shutter ............. Auto (1/60 sec. - 1/100,000 sec.)
S/N Ratio .......................... More than 52dB
Backlight Compensation ..... Auto
White Balance .................. Auto
AGC .................................. Auto
Gamma ............................. 0.45 typ.
Scanning System.............. 2:1 interlace
Synchronization ................ Internal
Video Signal Output .......... 1.0Vp-p / 75 ohms
Operating Temperature ..... 14° F – 122° F
Storage Temperature ........ -4° F – 140° F
Power Consumption ......... Max. 80mA (IR off)
VLEDT1HG/VLEDT1HW: max. 400mA (IR on)
VLEDT2HG/VLEDT2HW: max. 300mA (IR on)
Power Supply ................... 12VDC (power supply not included)
Dimensions ....................... VLEDT1HG/VLEDT1HW: 4.25” (H) x 4.5” (Dia.)
VLEDT2HG/VLEDT2HW: 3.2” (H) x 3.6” (Dia.)
Weight .............................. VLEDT1HG/VLEDT1HW: 1.2 lbs.
VLEDT2HG/VLEDT2HW: 10.4 oz.
960H IR Indoor/Outdoor Turret Camera
VLEDT1HG 2.8-12mm auto iris varifocal lens, dark grey housing
VLEDT1HW 2.8-12mm auto iris varifocal lens, white housing
VLEDT2HG 3.6mm xed lens, dark grey housing
VLEDT2HW 3.6mm xed lens, white housing
Features
Speco Technologies is constantly developing and improving products.
We reserve the right to modify product design and specications without notice
and without incurring any obligation. Spec Rev. 8/25/14
800-645-5516 • Fax: 631-957-9142 or 631-957-3880 • specotech.com
PSW5
12VDC
Power Supply
4.5” (Dia.)
4.25” (H)
3.6” (Dia.)
3.2” (H)
VLEDT1HG/ VLEDT1HW VLEDT2HG/ VLEDT2HW
• 1/3” 960H CCD
• 0 lux with 36 IR LEDs built-in (VLEDT1HG/VLEDT1HW)
0 lux with 24 IR LEDs built-in (VLEDT2HG/VLEDT2HW)
• 98’ IR range (depending on scene reection) (VLEDT1HG/VLEDT1HW)
65’ IR range (depending on scene reection) (VLEDT2HG/VLEDT2HW)
• IP66 compliant
• 2 year warranty
