S
S
P
P
I
I
P
P
– Network Surge Protector
Features:
Protects equipment from high voltage surges from nearby lightning strikes.
Perfect for Network, PC modem, server…etc
Protects UTP Twisted Pair products or any computer equipment with networking cable.
Four pairs protection for wide range of applications: CCTV systems, video cameras,
monitors, multiplexers & Quad processors, NVRs, etc.
For network signals only – NOT for PoE signals
Installation View:
Specification
Item SPIP
Surge Protection Attack Time 1 ns
Maximum Surge Voltage 4 KV
Surge Life 300 surges of 100Amps
Normal Resistance Across Coax
10,000 MΩ
Surge Resistance Approx. 0Ω
BAND PASS 0~1 GHZ
Signal Passing Capability
Breakdown Voltage 7.6V / Clamping Voltage 10.0V
Insertion Loss Less than 0.2 dB
Return Loss (100 ohms) 16dB
Connectors RJ45
Dimensions in. 2.6 x 3.4 x 1
Weight lbs. 0.28
Rev. B
Speco Technologies is constantly developing and improving products.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
Speco Technologies ● 200 New Highway ● Amityville ● NY ● 11701 ● www.specotech.com
Rev. 03/31/20
