Speco Technologies
Ikke kategoriseret
IPPOERPT
Speco Technologies IPPOERPT Brugsanvisning
Her er Speco Technologies IPPOERPT (Ikke kategoriseret) brugervejledning. 2 sider på sprog med en vægt på 511,231.0 Mb. Hvis du ikke kan finde svar på dit problem Spørg vores community.
Side 1/2
1
I
I
P
P
P
P
O
O
E
E
R
R
P
P
T
T – Power over Ethernet (PoE) Repeater
Speco Technologies’ IPPOERPT is a PoE repeater that extends power and data an
additional 328’. A second unit can be used for a possible max distance of 980’,
eliminating the need for additional switches, hubs and expensive fiber installations.
The IPPOERPT is compliant with standard POE IEEE802.3af.
Features:
Extends both power and data over 300’.
Can use a second unit (not included) for a total transmission distance of 980’.
No external power is required.
Meets IEEE 802.3af POE standard.
Auto-sensing to detect PoE or non-PoE devices.
Supports 10/100/1000 BASE-T transmission rate.
Built in LED status indicator.
Plug and play for easy installation.
Installation View:
A single IPPOERPT itself provides 328’ of data and power, but the power capability
will drop with an additional receiver:
Panel View:
Max Device Power
Range with PoE switch
1
st
IPPOERPT Max. 2
nd
IPPOERPT Max.
8.58W at 656’ 4.21W at 980’
328’
328’
328’
Problemløsning Speco Technologies IPPOERPT
Hvis du har læst manualen omhyggeligt, men ikke fundet en løsning på dit problem, bed andre brugere om hjælp
Specifikationer
| Mærke: | Speco Technologies |
| Kategori: | Ikke kategoriseret |
| Model: | IPPOERPT |
