SPECIFICATION
960H 700TVL IR Mini Turret Camera (0.00 LUX)
BUILT-IN 10 POWER INFRARED LEDS
WEATHER / VANDAL RESISTANT
MODEL NO. HT71HG / W
Image Sensor 1/3" 960H COLOR CCD
Lens 2.9 mm
Number of Pixels 976(H) *508(V)
Horizontal Resolution 700TVL
Minimum Illumination 0.00Lux (LED ON)
Electronic Shutter Speed 1/60~1 / 100,000sec
S/N Ratio More than 48dB
Scanning System 2 : 1 Interlaced
Sync. System Internal
Video Output 1.0Vp-p 75ohm composite
Power Consumption -O (100mA), IR-On (200mA) at DC12V IR
Operating Temperature 14’F – 120’F
Weight 4oz.
GENERAL FEATURE
• 700TVL HIGH RESOLUTION
• 10IR LEDs / 35’ IR range
* Only 1.58 in diameter
• Weather / Vandal Resistant
• IP66 compliant
1) Connect Video & Power Line (12V DC Regulated Power)
2) Please set the position where you want to connect the
camera
3) Loosen the locking screws and adjusting camera angle
4) Combine each camera parts and lock & tight the each
locking screws
Model No. : HT71HG and HT71HW
INSTALLATION
200 New Highway, Amityville, NY 11701
800 645- -5516 / www.specotech.com
*Accessory *
3 mounting screw
1 wrench
