960H 700TVL Miniature IR Bullet Camera
GENERAL FEATURE
•700 lines of color resolution
1) Connect Video & Power Line (Power supply not included)
Model No. : HT637H (Grey housing)
HT637HW (White housing)
INSTALLATION
200 New Highway, Amityville, NY 11701
800-645-5516 / www.specotech.com
*Accessories *
3 Mounting screws
1 Mounting bracket
[Front View] [Side View]
Unit : inch
SPECIFICATIONS
MODEL NO.
HT637H (Grey Housing)
HT637HW (White housing)
Image Sensor 1/3" 960H COLOR CCD
Lens 3.6mm Fixed Lens
Number of Pixels 976(H) x 494(V)
Horizontal Resolution 700TVL
Minimum Illumination 0.00Lux (IR LED On)
Electronic Shutter Speed 1/60~1 / 100,000sec
S/N Ratio More than 48dB
Scanning System 2 : 1 Interlaced
Sync. System Internal
Video Output 1.0Vp-p 75ohm composite
Power Consumption 100mA (IR off) / 200mA (IR On) at 12VDC
Operating Temperature 14
F – 120
F
Weight 5oz.
•10 IR LEDs for 35ft. operation
•Miniature bullet type
•Weather resistant operation
•12VDC operation
2) Set the position where you want to connect the camera
3) Loosen the locking screws and adjust the camera angle
4) Combine each camera part and lock & tighten each locking
screw
