Speco Technologies’ HD2SPL2 allows you to distribute one HDMI source to four displays simultaneously without any
signal loss. The splitter is compatible with HDMI 1.4V, 3D and 4Kx2K ultra HD.
Features:
• Supports full 3D pass-through
• Supports 4K x 2K high resolution
• HDCP 1.3
• Includes 5V power supply
Panels
Front Panel
1) HDMI Output
2) IR Output
3) Power LED
4) Reset Button
Rear Panel
1) HDMI Output
2) HDMI Input
3) Power Supply Input
Instructions:
1. Connect HDMI input ports to HD signal source devices such as Set-top box, DVR/NVR, Blueray player, etc.
2. Connect HDMI output ports to HDMI displays
3. Connect 5V power supply to unit and then to power source
Specifications:
Input Ports 1 x HDMI (Female)
Output Ports 4 x HDMI (Female)
Bandwidth 10.2Gbps
Output Resolution 480i-1080p@50/60, 1080p@24/50/60, 2160p@24/30, VGA-UXGA
Operating Temperature 5°F to 131°F (-15°C to 55°C)
Deep Color 36 bit
Case Metal
Dimensions L x W x H 4.7” x 2.4” x 0.7” (120mm x 60mm x 18mm)
Weight 0.44 lbs (200g)
Power DC 5V 1A
Speco Technologies is constantly developing and improving products.
We reserve the right to modify product design and specifications without notice and without incurring any obligation.
Speco Technologies ● 200 New Highway ● Amityville ● NY ● 11701 ● www.specotech.com
Rev. 04/08/20
