l ITEM №: H5T1M
l Caution for Installation
1. In order to prevent electronic shock, don’t loosen any screws or covers.
2. Do not directly touch the front glass. If necessary, use a soft cloth
moistened with alcohol to wipe off the dust.
3. Avoid places where there are frequent vibrations or shocks.
4. Don’t operate the camera beyond its temperature, power source ratings.
5. When any abnormalities happen, make sure to unplug the camera and
contact your local dealer.
l Packing
1. Camera X1
2. Junction box X1
3. User Manual X1
4. 4*34mm Screw X4
5. 4*20mm Screw X4
6. Plastic-Conical-Anchor X4
7. Junction box cotton pad X1
8. Hexagonal Wrench X1
9. Mounting drawing paper X1
10. Screw nut waterproof ring X1
11. Screw Silica Ring X4
12. Dome base rubber ring X1
13. Power Connector Cable X1
l Specification
ITEM
H5T1M
IP Rating
IP66
Type
Removable IR Cut Filter
Signal System
NTSC/PAL
Pick Up Device
1/2.8” 5M SONY CMOS
Picture Elements
2688 (H)X1944 (V)
Min Illumination
0Lux（24 Pieces IR LED ON）
S/N Ratio
≥50dB
Lens
2.7-13.5mm Motorized Varifocal Fixed Iris Lens
3D
ON
Back Light Compensation
OFF
WDR
ON/OFF
OSD
With UTC Signal (DVR Control OSD)
Video Out-put
5MP TVI/AHD,4MP&2MP TVI/AHD/CVI,CVBS
Power Supply
DC12V ±10%
Current Consumption
600mA(MAX)
IR Effect Distance
49.2~65.6ft(indoor)
Dimension
Φ4.72”×3.93” inch
Weight
790g（27.86oz）
Storage Temperature
-22～+149℉
Operating Temperature
-22～+122℉
Junction box
Dimension
Φ4.72””×1.59” inch
Weight
255g (9.0oz)
Remark: Non-regulative adaptor may cause camera damaged.
l video signal output switches
5MP 4in1 Motorized Eyeball Camera with Junction Box
