HDMI and IR Extender Over LAN
BREAK DISTANCE BARRIERS
TO EXTEND HDMI AND
IR SIGNALS OVER IP
USING CAT5E/6 CABLES
Quick Start Guide
VIDEO
Format HDMI 1.3 and HDCP compliant
HDTV Resolutions
480p, 720p, 1080i,
1080p/60Hz/48bit
TV Resolution 480i
Input Interface (TX) HDMI Type A 19-pin Female TMDS
Output Interface (RX) HDMI Type A 19-pin Female TMDS
Input Cable Length Up to 40 ft
Output Cable Length Up to 40 ft
AUDIO
Format Dolby TrueHD, DTS-HD MA
Input Interface HDMI (Integrated)
Output Interface HDMI (Integrated)
IR
Signal Type 38 KHz
Interface 3.5 mm Jack Socket (Female)
SYSTEM
Interface RJ-45
Cable Requirements CAT5/5e/6
Maximum Length 500 f
OTHER
Power
External 100-240 VAC/5VDC2A
@10W
Dimensions 2.78” W x 1.125” H x 4” D
Weight 0.45 lbs
Approvals UL, CE, ROHS Compliant
Operating Temp. 32-104°F (0-40 °C)
Storage Temp. -4-140°F (-20-60 °C)
Humidity Up to 85% (non-condensing)
NOTICE
The information contained in this document is
subject to change without notice. SmartAVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties of
merchantability and tness for particular purpose.
SmartAVI will not be liable for errors contained
herein or for incidental or consequential damages in
connection with the furnishing, performance or use of
this material.
No part of this document may be photocopied,
reproduced, or translated into another language
without prior written consent from SmartAVI
Technologies, Inc.
800.AVI.2131, 702.800.0005
2455 W Cheyenne Ave, Suite 112
North Las Vegas, NV 89032
SmartAVI.com
TECHNICAL SPECIFICATION
HLX-500
WHAT’S IN THE BOX
PART NO. DESCRIPTIONQ-TY
HLX-TX500 1
HDMI over LAN or CAT5e/6
Cable Transmitter
HLX-RX500 1
HDMI over LAN or CAT5e/6
Cable Receiver
Power Supply 2 PS5VD2A
Quick Start Guide 1
